Products
Showing 19–36 of 177 results
Avalue – ARC 10″ to 21.5″ IP Rated PCAP Panel PC
Avalue - ARC 10" to 21.5" IP Rated PCAP Panel PC
XProduct SKU: AVALUE: ARC 10" TO 21.5"-P
Designed for industrial applications such as factory automation interfaces, the Avalue ARC series rugged touch monitors feature die casting front bezels and PCAP coating technology enabling them to withstand harsh operating environments, while also being suitable for work, outdoor or public use-cases such as digital signage, transportation, vending machines, kiosks, ATMs, intercoms and much more
Features
- 10.1 ~ 21.5" Screen Size(s) - HDMI, VGA, Display Port - Vibration & Shock Protection - IP65 Compliant Front Panel - Option for Bi-Direction WIFI-6 - Wide Operating Temperature Specs Display Size 10.1" (16:10) - ARC-10W00. 12.1" (16:10) - ARC-1200. 15" (16:10) - ARC-1500. 15.6" (16:10) - ARC-15W00. 17" (16:10) - ARC-1700. 21.5" (16:10) - ARC-21W00. Resolution WXGA (1280 x 800) - ARC-10W00. 12.1" (16:10) - ARC-1200. 15" (16:10) - ARC-1500. 15.6" (16:10) - ARC-15W00. 17" (16:10) - ARC-1700. 21.5" (16:10) - ARC-21W00. Pixel Pitch (H) 0.1695mm x (V) 0.1695mm - ARC-10W00. (H) 0.240mm x (V) 0.240mm - ARC-1200. (H) 0.297mm x (V) 0.297mm - ARC-1500. (H) 0.252mm x (V) 0.252mm - ARC-15W00. (H) 0.264mm x (V) 0.264mm - ARC-1700. (H) 0.24795mm x (V) 0.24795mm - ARC-21W00. Luminance 350 cd/m2 - ARC-10W00. 600 cd/m² - ARC-1200. 300 cd/m² - ARC-1500. 300 cd/m² - ARC-15W00. 350 cd/m² - ARC-1700. 250 cd/m² - ARC-21W00. Contrast ratio 800 - ARC-10W00. 1000 - ARC-1200. 2000 - ARC-1500. 500 - ARC-15W00. 800 - ARC-1700. 250 cd/m² - ARC-21W00. I/O Interface USB Type B connector for touch function 1 x HDMI 1.4a (HDCP 1.3). 1 x Display Port 1.2 (HDCP 1.3). 1 x 15 PIN D-SUB VGA connector Other OSD key at rear cover. Expansion Option for Bi-Direction WIFI-6 Interactive Module for USB Signal and Image. Audio 1 x Line in. 2 x 5W Speaker Output. Power Input: 100 ~ 240Vac/ 50 ~ 60Hz. Output: 60W Adapter (12V @ 5A Adapter) AC-DC Adapter. +12V DC in by DC Jack. Optional: +9~36V DC in by phoenix connector. Operating Temperature 10°C ~ 50°C - ARC-10W00. -10°C ~ 50°C (Option for -20°C ~ 70°C) - ARC-1200. -10°C ~ 50°C (Option for -20°C ~ 70°C) - ARC-1500. -10°C ~ 50°C (Option for -10°C ~ 60°C) - ARC-15W00. 10°C ~ 50°C (Option for -20°C ~ 70°C) - ARC-1700. 10°C ~ 50°C - ARC-21W00. Storage Temperature 20°C ~ 60°C - ARC-10W00. 20°C ~ 70°C - ARC-1200. 20°C ~ 70°C - ARC-1500. -20°C ~ 60°C - ARC-15W00. -20°C ~ 70°C - ARC-1700. 20°C ~ 60°C - ARC-21W00. Shock MIL-STD-810G, Method 516.6, Procedure I, functional shock=20G. Vibration 1.5Grms, IEC 60068-2-64, Random, 5 ~ 500Hz, 1hr/axis. IP Rating Front Panel IP65. Dimensions (W x L x D) 282.3 x 201 x 61.4 mm - ARC-10W00. 293.77 x 226.3 x 61.5 mm - ARC-1200. 350 x 274.5 x 63.5 mm - ARC-1500. 391.21 x 239.21 x 68 mm - ARC-15W00. 392.72 x 325.32 x 70.25 mm - ARC-1700. 538.05 x 341.05 x 71 mm - ARC-21W00. Weight 2 kg - ARC-10W00. 2.5 kg - ARC-1200. 3.7 kg - ARC-1500. 3.2 kg - ARC-15W00. 4.6 kg - ARC-1700. 5.9 kg - ARC-21W00. Mounting Wall / Stand / VESA 75mm x 75mm, 100mm x 100mm. Default with Panel Mount kits. Certification CE/FCC Class A. OS Support Windows© 10. Linux.CONTACT US FOR VOLUME PRICING
Enquire for availability
Make an Enquiry
Avalue – ARC-10W33 IP Rated PCAP Panel PC POE Options Windows /Linux/Android
Avalue - ARC-10W33 IP Rated PCAP Panel PC POE Options Windows /Linux/Android
XProduct SKU: ARC-10W33
10.1" WXGA LCD with P-cap Intel® Celeron® N3350 Rugged Touch Panel PC with IET Expansion
Features
- 10.1" WXGA LCD with PCAP Multi-Touch - Onboard Intel® Celeron® N3350/J3455 SoC BGA Processor - 1 x 204-pin DDR3L SODIMM Socket, Supports Up to 8GB DDR3L 1600MTs SDRAM - Rich I/Os, 2 LAN, 2 COM, 4 USB, SIM Card Slot, Swappable Drive Bay, Speaker out for Flexible Expansion Modules - 1 x Mini PCIe Slot - Rugged Design for Vibration & Shock Protection, Cableless Design - Fanless Operation from -10 ~ 50°C - Wide Range DC Power Input from +9 ~ 36Vdc - Service Window, Easy to Install Memory Module - Front panel: IP65, Rear: IP41(except I/O) - PM2.0 (optional)Specifications
System Information
Processor Onboard Intel® Celeron® SoC BGA Processor (Apollo Lake Platform N3350/J3455 CPU) System Memory One 204-pin DDR3L SODIMM Socket, Supports Up to 8GB DDR3L 1600Mhz SDRAM (Non-ECC) Watchdog Timer H/W Reset, 1sec. ~ 65535sec./1sec.step H/W Status Monitor Monitoring CPU & System Temperature and Voltage CPU Cooler (Type) Fanless HeatsinkExpansion
Expansion 1 x mSATA supports on the 1st Mini PCIe slot, Auto switch for mSATA or Mini PCIe 1 x 80-pin IET interfaceStorage
Storage 1 x 2.5" Drive Bay(7mm HDD Restricted) HDD/ SSD 1 x SATA3 Other Storage Device 1 x mSATA supports on the 1st Mini PCIe slot, Auto switch for mSATA or Mini PCIeI/O
USB Port 4 x USB3.0 (2 x Double deck) COM Port 1 x RS-232/422/485, selectable by BIOS, RS-485 supports Auto Flow, Pin-9 selected by Ring/+5V/+12V) 1 x RS-232 DIO 16-bit GPIO Expansion 1 x mSATA supports on the 1st Mini PCIe slot, Auto switch for mSATA or Mini PCIe 1 x Optional by IET module Other 3 x Knockouts for Antenna MountingPanel
LCD Size 10.1" 16:10 Display Type WXGA B/L Inverter/Converter LCD built in Resolution 1280x800 Pixel pitch 0.1695mm(H) x 0.1695mm(V) Luminance 350 cd/m2 Contrast ratio 800 Viewing angle 85 (U), 85 (D), 85 (L), 85 (R) Response time 25 ms Backlight LED Touch Type PCAP Multi-Touch support up to 10 points Touch Light Transmission 88 % Touch Controller EETII/O
USB Port 4 x USB3.0 (2 x Double deck) COM Port 1 x RS-232/422/485, selectable by BIOS, RS-485 supports Auto Flow, Pin-9 selected by Ring/+5V/+12V) 1 x RS-232 DIO 16-bit GPIO Expansion 1 x mSATA supports on the 1st Mini PCIe slot, Auto switch for mSATA or Mini PCIe 1 x Optional by IET module Other 3 x Knockouts for Antenna MountingCertifications
Certification Information CE / FCC Class BEthernet
LAN Port 2 x Intel I211AT for APL-MPower Requirement
DC Input
DC +9V ~ +36V, wide voltage single power input
TVS component for surge protection
Reverse current/voltage protection
DC Input Connector Lockable DC Jack (Default)
optional for phoenix connector
ACPI Single power ATX Support S0, S3, S4, S5 and ACPI 3.0 Compliant
Power Mode AT/ATX
Adapter Input: 100 ~ 240Vac/ 50 ~ 60Hz Output: 60W Adapter (12V @ 5A Adapter) AC-DC Adapter
Mechanical & Environmental
Operating Temperature -10°C ~ 50°C
Storage Temperature -20°C ~ 60°C
Operating Humidity 40°C @ 95% Relative Humidity, Non-condensing
Dimension (W x L x H) 282.29 x 200.93 x 50.9mm
Weight 2.17Kgs
Vibration Test With SSD/mSATA : 1.5Grms, IEC 60068-2-64, Random, 5 ~ 500Hz, 1hr/axis
Shock Test Operating with SSD/CFast/mSATA : MIL-STD-810G, Method 516.6, Procedure I, functional shock=20G
IP Rating Front Panel IP65
back cover IP41
Mounting Kit Wall / Stand / VESA 75mm x 75mm, 100mm x 100mm
Panel Mount with mounting kits
Power Requirement DC +9V ~ +36V, wide voltage single power input
TVS component for surge protection
Reverse current/voltage protection
Power Mode AT/ATX
System Fan Fanless
Construction - Front Die Casting with Cover lens
Construction - Rear Black Die Casting
Relative Humidity 40°C @ 95% Relative Humidity, Non-condensing
Fanless Yes
Drop ISTA 2A, IEC-60068-2-32 Test:Ed
Software Support
OS Information Linux, Windows 10
Ordering Information
Ordering Information
ARC-10W33-33-B3-1R
Intel® Celeron® Processor N3350 1.10GHz F1-CPU/2GLAN/2COM/4USB/SPK/12V Adapter/PCAP
ARC-10W33-34-B3-1R
Intel® Celeron® Processor J3455 1.50GHz F1-CPU/2GLAN/2COM/4USB/SPK/12V Adapter/PCAP
ACC-ARC-USB-1R
4 x USB 3.0 Kit for ARC Series
ACC-ARC-AUDIO-1R
HDMI + 5.1 CH Audio Kit for ARC Series
ACC-ARC-MPCIE-1R
HDMI + MPCIE w/SIM Kit for ARC Series
ACC-ARC-COM-1R
2 x Isolated RS-232 Kit for ARC Series
ACC-ARC-COM-2R
3 x RS-232 Kit for ARC Series
ACC-ARC-COM-3R
2 x RS-232 + USB Kit for ARC Series
ACC-ARC-COM-4R
2 x RS-232 + LAN Kit for ARC Series
ACC-ARC-GPIO-1R
12-bit GPIO + 2-pin CAN Bus Kit for ARC Series
ACC-ARC-OBDII-1R
OBDII - CAN Bus Kit for ARC Series (OBDII/EOBD for Small Vehicle)
ACC-ARC-OBDII-2R
OBDII - CAN Bus Kit for ARC Series (J1939J1708 for Large Vehicle)
ACC-ARC-OBDII-3R
OBDII - CAN Bus Kit for ARC Series (ISO15765-4 for Special Large Vehicle)
E1702031833R USA Power Cord
E1702031000R EU Power Cord
E1702031834R Japan Power Cord
E1702031830R UK Power Cord
E1702031831R Australia Power Cord
CONTACT US FOR VOLUME PRICING
Enquire for availability
Make an Enquiry
Avalue – ARC-15W33 15.6” WXGA LCD with PCAP Multi-Touch Fanless Panel PC Intel® Celeron® N3350/J3455 with IEn
Avalue - ARC-15W33 15.6” WXGA LCD with PCAP Multi-Touch Fanless Panel PC Intel® Celeron® N3350/J3455 with IEn
XProduct SKU: ARC-15W33-335-B2R
The ARC series are suitable for using in diverse application scenarios, including industrial automation (e.g. HMI, heavy-industry manufacturing, non-stop production process and industrial automation), rehabilitation equipment (e.g. decompression machine, rehabilitation machine and training machine), and automated kiosks (e.g. automated vending machine, ATM, interactive kiosk and payment machine). The emphasis of Avalue’s ARC series design includes IP-65 rated water and dust resistance, wide operating temperature range, sunlight readable, support 5G and Wi-Fi 6 wireless transmission, and coating technology for PCAP touchscreen, making it the ideal solution for all applications whether indoor or outdoor.
Features
System Information Processor Onboard Intel® Celeron® SoC BGA Processor (Apollo Lake Platform N3350/J3455 CPU) System Memory 1 x 204-pin DDR3L SODIMM Socket, Supports Up to 8GB DDR3L 1600Mhz SDRAM (Non-ECC) Watchdog Timer H/W Reset, 1sec. ~ 65535sec./1sec.step H/W Status Monitor Monitoring CPU & System Temperature and Voltage CPU Cooler (Type) Fanless Heatsink Expansion Expansion 1 x mSATA supports on the 1st Mini PCIe slot, Auto switch for mSATA or Mini PCIe 1 x 80-pin IET interface Storage Storage 1 x 2.5” Drive Bay(7mm HDD Restricted) HDD/ SSD 1 x SATA3 Other Storage Device 1 x mSATA supports on the 1st Mini PCIe slot, Auto switch for mSATA or Mini PCIe Panel LCD Size 15.6", 16:9 Display Type WXGA B/L Inverter/Converter LCD built in Resolution 1366 x 768 Pixel pitch 0.252mm(H) x 0.252mm(V) Luminance 300 cd/m² Contrast ratio 500 Viewing angle 80 (U), 80 (D), 80 (L), 80 (R) Response time 8 ms Backlight LED Touch Type Projective Capacitive Multi-Touch supports up to 10 points Touch Light Transmission 88 % Touch Controller EETI I/O USB Port 4 x USB3.0 (2 x Double deck) COM Port 1 x RS-232/422/485, selectable by BIOS, RS-485 supports Auto Flow, Pin-9 selected by Ring/+5V/+12V) 1 x RS-232 DIO 16-bit GPIO Expansion 1 x mSATA supports on the 1st Mini PCIe slot, Auto switch for mSATA or Mini PCIe 1 x Optional by IET module Other 3 x Knockouts for Antenna Mounting System Control LED Indicator HDD LED, Power LED DC In/Out Characteristics Power Type AT/ATX Audio Audio Codec Realtek ALC888S Audio Interface speaker out Speaker Output 2 x 2W Certifications Certification Information CE / FCC Class B Ethernet LAN Port 2 x Intel I211AT for APL-M Power Requirement DC Input DC +9V ~ +36V, wide voltage single power input TVS component for surge protection Reverse current/voltage protection DC Input Connector Lockable DC Jack (Default) optional for phoenix connector ACPI Single power ATX Support S0, S3, S4, S5 and ACPI 3.0 Compliant Power Mode AT/ATX Adapter Input: 100 ~ 240Vac/ 50 ~ 60Hz Output: 60W Adapter (12V @ 5A Adapter) AC-DC Adapter Mechanical & Environmental Operating Temperature -10°C ~ 50°C Storage Temperature -20°C ~ 60°C Operating Humidity 0% ~ 90% Relative Humidity, Non-condensing Dimension (W x L x H) 391.2 x 239.2 x 57.5 mm Weight 3.7Kgs Vibration Test With SSD/mSATA : 1.5Grms, IEC 60068-2-64, Random, 5 ~ 500Hz, 1hr/axis Shock Test Operating with SSD/CFast/mSATA : MIL-STD-810G, Method 516.6, Procedure I, functional shock=20G IP Rating Front Panel IP65 back cover IP41 Mounting Kit Wall / Stand / VESA 75mm x 75mm, 100mm x 100mm Panel Mount with mounting kits Power Requirement DC +9V ~ +36V, wide voltage single power input TVS component for surge protection Reverse current/voltage protection Power Mode AT/ATX (ATX is default setting) System Fan Fanless Construction - Front Die Casting with Cover lens Construction - Rear Black Die Casting Relative Humidity 0~90% Relative Humidity, Non-condensing Fanless Yes Drop ISTA 2A, IEC-60068-2-32 Test:Ed Software Support OS Information Linux, Windows 10 Ordering Information Ordering Information ARC-15W33-335-B3R 15.6" 1366x768 Industrial Touch Panel PC, ErP Design, PCAP Multi Touch (F1 Stepping CPU) Intel Celeron SoC N3350 1.10GHz CPU/2GLAN/2COM/4USB/SPK/9~36V input/12V Adapter ARC-15W33-345-B3R 15.6" 1366x768 Industrial Touch Panel PC, ErP Design, PCAP Multi Touch (F1 Stepping CPU) Intel Celeron SoC J3455 1.50GHz CPU/2GLAN/2COM/4USB/SPK/9~36V input/12V Adapter ACC-ARC-USB-1R 4 x USB 3.0 Kit for ARC Series ACC-ARC-AUDIO-1R HDMI + 5.1 CH Audio Kit for ARC Series ACC-ARC-MPCIE-1R HDMI + MPCIE w/SIM Kit for ARC Series ACC-ARC-COM-1R 2 x Isolated RS-232 Kit for ARC Series ACC-ARC-COM-2R 3 x RS-232 Kit for ARC Series ACC-ARC-COM-3R 2 x RS-232 + USB Kit for ARC Series ACC-ARC-COM-4R 2 x RS-232 + LAN Kit for ARC Series ACC-ARC-GPIO-1R 12-bit GPIO + 2-pin CAN Bus Kit for ARC Series ACC-ARC-OBDII-1R OBDII - CAN Bus Kit for ARC Series (OBDII/EOBD for Small Vehicle) ACC-ARC-OBDII-2R OBDII - CAN Bus Kit for ARC Series (J1939J1708 for Large Vehicle) ACC-ARC-OBDII-3R OBDII - CAN Bus Kit for ARC Series (ISO15765-4 for Special Large Vehicle)CONTACT US FOR VOLUME PRICING
Enquire for availability
Make an Enquiry
Avalue – ECM-APL Intel® Pentium®/Celeron®/Atom® SoC Processor 3.5”Micro Module
Avalue - ECM-APL Intel® Pentium®/Celeron®/Atom® SoC Processor 3.5”Micro Module
XProduct SKU: ECM-APL
Top Layer SolderedIntel® Pentium®/Celeron®/Atom™ BGA ProcessorIntel® HD Graphics 500/505 Graphic EngineSingle DRAM Socket, Max. Up to 8GB DDR3L 1600&1333MHzTriple Display (Dual HDMI, LVDS)Dual Expansion Slot, M.2 & mPCIeDual Gigabit Ethernet, HD Audio Code0~60C for N & J Series, -40~85C for E SeriesTPM 2.0 (Factory Option)
Features
System Information Processor Intel Atom® x7-E3950 Processor (2M Cache, up to 2.00 GHz) Intel Atom® x5-E3940 Processor (2M Cache, up to 1.80 GHz) Intel Atom® x5-E3930 Processor (2M Cache, up to 1.80 GHz) Intel® Pentium® Processor N4200 (2M Cache, up to 2.50 GHz) Intel® Celeron® Processor N3350 (2M Cache, up to 2.40 GHz) Intel® Celeron® Processor J3455 (2M Cache, up to 2.30 GHz) Platform Controller Hub Apollo SoC integrated System Memory 1 x 204-Pin DDR3L 1600&1333MHz SO-DIMM,supports up to 8GB (Non-ECC) I/O Chipset EC(IT8528E), I-series CPU use EC (IT8528I) for WT BIOS Information AMI uEFI BIOS,128Mbit SPI Flash ROM Watchdog Timer H/W Reset, 1sec. ~ 65535sec. and 1sec./step H/W Status Monitor Monitoring System Temperature, Voltage and FAN Status with Auto Throttling Control Expansion Expansion 1 x Mini PCIe (for PCIe & USB2.0) 1 x M.2 (2242)B-Key Storage Storage 1 x M.2 support SATA/USB interface & with Micro SIM card connector for SSD/3G/4G Touch Screen Built-in Touch controller (optional) EETI ETP-CP-MER4485XRU 1 x 5-pin 2.54mm Pin Header I/O USB Port 1 x USB 2.0 4 x USB 3.0 COM Port 1 x RS-232/422/485 5 x RS-232 GPIO 1 x 8bit GPIO SIM Slot 1 x Micro SIM Card Slot SATA 1 x SATA3 MIO 1 x LPC 1 x SPI Display Graphic Chipset Intel® Apollo Lake SoC integrated Gen9 LP Graphics Spec. & Resolution 2 x HDMI: Max. Resolution 3840x2160 @ 30Hz 1 x LVDS: Max. Resolution 1920x1080 @ 60Hz Multiple Display Triple Display Audio Audio Codec Realtek ALC888S supports 5.1-CH Audio Interface Mic-In, Line-In, Line-Out Certifications Certification Information CE,FCC Class B Ethernet LAN Chipset 2 x Intel® I211AT Intel I210IT for WT Ethernet Interface 10/100/1000 Base-Tx GbE compatible LAN Port 2 x RJ-45 Mechanical & Environmental Operating Temperature 0°C ~ 60°C (32°F ~ 140°F)(N4200/N3350) -40°C ~ 85°C (-40°F ~ 185°F)(E3900 Series)(Optional for Wide Temperature Model) Storage Temperature -40°C ~ 75°C (-40°F ~ 167°F) Operating Humidity 40°C @ 95% Relative Humidity, Non-condensing Weight 0.44lbs (0.2kg) Power Requirement Typical 12/24Vdc (+12V ~ +26V ) Power Mode AT/ATX Dimension (L x W) 5.7" x 4" (146mm x 101mm) Software Support OS Information Win 10, Linux Ordering Information Ordering Information ECM-APL-N4200-C1R 3.5" W/N4200/5USB/6COM/2LAN/C1 ECM-APL-N3350-C1R 3.5" W/N3350/5USB/6COM/2LAN/C1 ECM-APL-J3455-C1R 3.5" W/J3455/5USB/6COM/2LAN/C1 ECM-APL-E50-C1R(0~+60C) 3.5" W/E3950/5USB/6COM/2LAN/C1 ECM-APL-E40-C1R(0~+60C) 3.5" W/E3940/5USB/6COM/2LAN/C1 ECM-APL-E30-C1R(0~+60C) 3.5" W/E3930/5USB/6COM/2LAN/C1 ECM-APL-E50W-C1R(Wide temp.-40~+85C) 3.5" W/E3950/5USB/6COM/2LAN/C1 ECM-APL-E40W-C1R(Wide temp.-40~+85C) 3.5" W/E3940/5USB/6COM/2LAN/C1 ECM-APL-E30W-C1R(Wide temp.-40~+85C) 3.5" W/E3930/5USB/6COM/2LAN/C1Specifications
ystem Information Processor Intel Atom® x7-E3950 Processor (2M Cache, up to 2.00 GHz) Intel Atom® x5-E3940 Processor (2M Cache, up to 1.80 GHz) Intel Atom® x5-E3930 Processor (2M Cache, up to 1.80 GHz) Intel® Pentium® Processor N4200 (2M Cache, up to 2.50 GHz) Intel® Celeron® Processor N3350 (2M Cache, up to 2.40 GHz) Intel® Celeron® Processor J3455 (2M Cache, up to 2.30 GHz) Platform Controller Hub Apollo SoC integrated System Memory 1 x 204-Pin DDR3L 1600&1333MHz SO-DIMM,supports up to 8GB (Non-ECC) I/O Chipset EC(IT8528E), I-series CPU use EC (IT8528I) for WT BIOS Information AMI uEFI BIOS,128Mbit SPI Flash ROM Watchdog Timer H/W Reset, 1sec. ~ 65535sec. and 1sec./step H/W Status Monitor Monitoring System Temperature, Voltage and FAN Status with Auto Throttling Control Expansion Expansion 1 x Mini PCIe (for PCIe & USB2.0) 1 x M.2 (2242)B-Key Storage Storage 1 x M.2 support SATA/USB interface & with Micro SIM card connector for SSD/3G/4G Touch Screen Built-in Touch controller (optional) EETI ETP-CP-MER4485XRU 1 x 5-pin 2.54mm Pin Header I/O USB Port 1 x USB 2.0 4 x USB 3.0 COM Port 1 x RS-232/422/485 5 x RS-232 GPIO 1 x 8bit GPIO SIM Slot 1 x Micro SIM Card Slot SATA 1 x SATA3 MIO 1 x LPC 1 x SPI Display Graphic Chipset Intel® Apollo Lake SoC integrated Gen9 LP Graphics Spec. & Resolution 2 x HDMI: Max. Resolution 3840x2160 @ 30Hz 1 x LVDS: Max. Resolution 1920x1080 @ 60Hz Multiple Display Triple Display Audio Audio Codec Realtek ALC888S supports 5.1-CH Audio Interface Mic-In, Line-In, Line-Out Certifications Certification Information CE,FCC Class B Ethernet LAN Chipset 2 x Intel® I211AT Intel I210IT for WT Ethernet Interface 10/100/1000 Base-Tx GbE compatible LAN Port 2 x RJ-45 Mechanical & Environmental Operating Temperature 0°C ~ 60°C (32°F ~ 140°F)(N4200/N3350) -40°C ~ 85°C (-40°F ~ 185°F)(E3900 Series)(Optional for Wide Temperature Model) Storage Temperature -40°C ~ 75°C (-40°F ~ 167°F) Operating Humidity 40°C @ 95% Relative Humidity, Non-condensing Weight 0.44lbs (0.2kg) Power Requirement Typical 12/24Vdc (+12V ~ +26V ) Power Mode AT/ATX Dimension (L x W) 5.7" x 4" (146mm x 101mm) Software Support OS Information Win 10, Linux Ordering Information Ordering Information ECM-APL-N4200-C1R 3.5" W/N4200/5USB/6COM/2LAN/C1 ECM-APL-N3350-C1R 3.5" W/N3350/5USB/6COM/2LAN/C1 ECM-APL-J3455-C1R 3.5" W/J3455/5USB/6COM/2LAN/C1 ECM-APL-E50-C1R(0~+60C) 3.5" W/E3950/5USB/6COM/2LAN/C1 ECM-APL-E40-C1R(0~+60C) 3.5" W/E3940/5USB/6COM/2LAN/C1 ECM-APL-E30-C1R(0~+60C) 3.5" W/E3930/5USB/6COM/2LAN/C1 ECM-APL-E50W-C1R(Wide temp.-40~+85C) 3.5" W/E3950/5USB/6COM/2LAN/C1 ECM-APL-E40W-C1R(Wide temp.-40~+85C) 3.5" W/E3940/5USB/6COM/2LAN/C1 ECM-APL-E30W-C1R(Wide temp.-40~+85C) 3.5" W/E3930/5USB/6COM/2LAN/C1CONTACT US FOR VOLUME PRICING
Enquire for availability
Make an Enquiry
Avalue – ECM-ASL
Enquire for availability
Make an Enquiry
Avalue – ECM-TGUC 11th Gen Intel® Core™ SoC i5/i3 BGA Processor 3.5” Micro Module
Avalue - ECM-TGUC 11th Gen Intel® Core™ SoC i5/i3 BGA Processor 3.5” Micro Module
XProduct SKU: ECM-TGUC
11th Gen Intel® Core™ SoC i5/i3 BGA Processor 3.5” Micro Module
Features
- Bottom Layer Soldered Processor - Single 260-pin SO-DIMM DRAM Socket, Max, Up to 32GB DDR4 3200MTs (non-ECC Supported) - Triple display, 2 x DP++, 1 x 2CH LVDS/1x eDP (Default LVDS) - Expansion Slot, M.2 Key-B, M.2 Key-E, M.2 Key-M - Dual Gigabit Ethernet, 1 x 2.5GbE, 1 x 1GbE - TPM - DC-Input, +12~+24VDCSpecifications
System Information
Processor Onboard 11th Gen. Intel® Core™ SoC i5/i3 BGA Processor Intel® Core™ i3-1115G4 (up to 4.1GHz, dual-core, 6M Cache, TDP: 28/15W) Intel® Core™ i5-1135G7 (up to 4.2GHz, quad-core, 8M Cache, TDP: 28/15W) System Memory Single 260-pin DDR4 SODIMM Socket, Supports Up to 32GB DDR4 3200MTs SDRAM (non ECC only) I/O Chipset NCT6126 BIOS Information AMI BIOS, 256Mbit SPI Flash ROM Watchdog Timer H/W Reset, 1sec. ~ 65535sec and 1sec. or 1min./step H/W Status Monitor CPU & system temperature monitoring Voltages monitoring TPM Onboard NuvoTon NPCT750AADYX support TPM 2.0, co lay Infineon SLB9670VQ2.0 & ???? Z32H330TC-SQN-755Expansion
Expansion 1 x M.2 Type M 2280 (with 1 x PCI-e Gen4 x4) 1 x M.2 Type B 3042/3052/2242 (with SATA and USB2.0, USB 3.0, with 1 x SIM card slot, support WWAN+GNSS or SSD) * Only supports one SIM card (co-lay 1 x 10pin FPC connector for uSIM card adapter) 3.8V for 5G 1 x M.2 Key E 2230 support WiFi module (1 x PCI-e x 1 & USB 2.0 Signal))Storage
Storage 1 x M.2 (Key-B, 3052) 1 x M.2 (Key-M, 2280) 1 x SATA IIII/O
USB Port 3 x USB 3.2 Gen 2x1 5 x USB 2.0 COM Port 1 x RS-232/422/485 5 x RS232 SATA 1 x SATA III DIO 1 x 2 x 6 pin, pitch 2.00mm connector for GPIO: 8 bits & +3.3S Level Other 2 x LANDisplay
Graphic Chipset Intel® Tiger Lake UP3 SoC Processor integrated Gen12 graphics Spec. & Resolution DP++ Max resolution 4096x2160@60Hz LVDS Max resolution 1920 x 1080 Dual channel 18/24-bits or 1x eDP 1920 x 1080@60Hz (2 Lanes), default LVDS Multiple Display Triple Display LVDS 1 x LVDS: 1920 x 1080 Dual channel 18/24-bits LVDS (Chrontel CH7513A-BF eDP to LVDS)Audio
Audio Codec RealTek ALC888S-VD2-GR Audio Interface Mic-In, Line-In, Line-Out in pin headerCertifications
Certification Information CE FCC Class BEthernet
LAN Chipset Intel® I219LM Gigabit Ethernet Intel® I225V Gigabit Ethernet Ethernet Interface 1 x 10/100/1000/2.5G Base-Tx GbE compatible 1 x 10/100/1000 Base-Tx GbE compatible LAN Port 2 x RJ-45Mechanical & Environmental
Operating Temperature Standard Temperature: 0°C ~ 60°C (-4~140°F) with 0.5m/s air flow Storage Temperature -40°C ~ 75°C (-40°F ~ 167°F) Operating Humidity 40°C @ 95% Relative Humidity, Non-condensing Weight 0.44lbs (0.2kg) Vibration Test 1.5Grms, IEC 60068-2-64, Random, 5 ~ 500Hz, 30min/Axis, 3 Axis Shock Test 10G, IEC 60068-2-27, Half Sine, 11ms, Z Axis Drop Test ISTA 2A, IEC-60068-2-32 Test : Ed, 1 Corner, 3 Edges, 6 Faces Power Requirement DC in +12V ~ +24V ACPI Single power ATX Support S0,S3, S4, S5 ACPI 5.0 Compliant Power Mode AT/ATX (Default Setting: AT) Dimension (L x W) 5.7" x 4" (146mm x 101mm)Software Support
OS Information Win 10 LinuxOrdering Information
Ordering Information ECM-TGUC-15-A1R, ECM-TGUC/i31115G4/1SATA/6COM/8USB/15W/A1 ECM-TGUC-35-A1R, ECM-TGUC/i51135G7/1SATA/6COM/8USB/15W/A1CONTACT US FOR VOLUME PRICING
Enquire for availability
Make an Enquiry
Avalue – EPB-1001 Battery Expansion Power Bank Battery Pack: UN38.3, UL2054, EN 62133-2:2017 (Battery body EN
Avalue - EPB-1001 Battery Expansion Power Bank Battery Pack: UN38.3, UL2054, EN 62133-2:2017 (Battery body EN
XProduct SKU: EPB-1001
EPB-1001 Battery Expansion Power Bank Easy installation at rear side of panel PC for mobile purpose or can be used as UPS solution.Support 6 to 12 hours operating depends on system power consumption.Compact Size to fit in most of main stream medical displays or panel PCs.Dual hot-swappable batteries.Optional VESA mounting bracket
Features
Easy installation at rear side of panel PC for mobile purpose or can be used as UPS solution.Support 6 to 12 hours operating depends on system power consumption.Compact Size to fit in most of main stream medical displays or panel PCs.Dual hot-swappable batteries.Optional VESA mounting bracketSpecifications
+ Spec System Information Platform Controller Hub LTC1760 Smart Charger IC LTC3789 Power IC SBC EPB-1001 battery board MCU IT8911 Battery Optional Dual Hot Swappable Smart Battery Pack 14.4V 6800mAh, 99.4Wh External I/O USB Port 1 x Type A Power Output 12/19V DC-out 80W (By Jumper Setting. Default set as 19V) Optional Y-Cable available System Control LED Indicator Battery 1/ Battery 2 on the side DC In / Out Connector Input Power Connector DC Jack with Lock Output Power Connector (DC-12V) 4P 90D(F) DC In/Out Characteristics Power Type 19V-24V Output Voltage Range 14.4V Per Battery Reliability Operating Temperature 0~40°C (32°F ~ 104°F) Operating Humidity 40°C @ 95% Relative Humidity, Non-condensing Storage Temperature -40°C ~ 75°C (-40 ~ 167°F) (without battery pack) Certifications Certification Information Battery Pack: UN38.3, UL2054, EN 62133-2:2017 (Battery body EN 62368-1) EPB-1001: EN 60601-1 IEC60601-1 compliance ISO 14971 (RMF) EN 60601-1-2 4th (EMI ClassB) FCC class part-15B (ITE) Mechanical & Environmental Weight 1.2kg Vibration Test 1.5 Grms, IEC 60068-2-64 Shock Test 10g, Half Sine, IEC 60068-2-29 VESA Optional VESA Bracket Kit (75x75/ 100x100) Dimensions(W x L x D) 235*182*36mm Fanless Yes Color White/ Blue Black (optional) Dust and Rain Test Top Side IPX1 + Ordering EPB-1001-891-A1R EPB-1001 Battery Expansion Box (Without Batteries) RCC-EPB-VESA-01R EPB-1001 VESA Bracket Kit RCC-HID-BAT-01R HID-2334 Totex Hot Swappable Battery, Pack of 4 RCC-HID-BATCHR-01R 4 Bay Charging Station w/120W Power Adapter E170U080090R External USB Cable 500mm E170P060330R External Power Output Cable 450mm DC Plug with lock E170P100110R External Power Output Y Cable DC Plug/ Power Din E170P080290R External Power Output Y Cable DC Plug/ Lockable DC Plug + Download Driver(1) Manual(1) Windows 10 64bit No. Release Date Model Description Download 1 2022-01-28 EPB-1001 BatteryManagement Tools Device:Other DownloadCONTACT US FOR VOLUME PRICING
Enquire for availability
Make an Enquiry
Avalue – EZX-EHLP Intel® Elkhart Lake 1.8”SBC
Avalue - EZX-EHLP Intel® Elkhart Lake 1.8”SBC
XProduct SKU: EZX-EHLP-P
Intel® Elkhart Lake 1.8"SBC
- Bottom Layer Soldered Processor - Intel® Atom® x6000E Series and Intel® Pentium® and Celeron® J Series processors - Onboard Single channel LPDDR4 4GB memory down (8GB for BOM option) - Dual Display, Mini DP, eDP 1.3 - M.2 Key-B 3042/2242 bridge bracket to 3052 (with PCI-e x2 (via OEM BIOS request) or default (PCI-e x1+USB2.0/USB3.0), or (SATAIII+ USB2.0/USB3.0), SIM Slot for SSD/LTE/IO Cards) with FPC connector - Single Intel® I210AT/IT Gigabit Ethernet - 1 x Dual deck USB3.1 gen2 Type A for 2 x USB 3.1 Gen2 at I/O, 4 x USB 2.0 by pin header - 1 x RS-232/422/485 - GPIO 8bit - DC-In+12VFeatures
System Information
Processor Onboard Intel® Pentium®/Celeron®/Atom™ SoC BGA Processor (Elkhart Lake Platform 4.5~12W)- (with CPU Bottom Mounted) Platform Controller Hub Elkhart lake SoC integrated System Memory Onboard Single channel LPDDR4 4GB memory down (8GB for BOM option) I/O Chipset EC ITE IT5571 BIOS Information AMI BIOS, 256Mbit SPI Flash ROM Watchdog Timer H/W Reset, 1sec. ~ 65535sec and 1sec. or 1min./step H/W Status Monitor CPU & system temperature monitoring Voltages monitoring TPM Onboard eMMC 5.1 64GB Expansion 1 x M.2 Type B 3042/2242 bridge bracket to 3052 (with PCI-e x2 (via OEM BIOS request) or default (PCI-e x1+USB2.0/USB3.0), or (SATAIII+ USB2.0/USB3.0), SIM Slot for SSD/LTE/IO Cards) *Default is PCI-e x1/SATAIII+USB2.0/USB3.0 support WWAN+GNSS or NVMe SSD Storage 1 x M.2 Type B I/O -USB Port - 1 x Dual deck USB3.1 gen2 Type A for 2 x USB 3.1 Gen2 at I/O 4 x USB2.0 fby pin header COM Port - 1 x RS232/422/485 DIO - 1 x 8-bit GPIO Display Graphic Chipset - Intel® UHD Graphics Spec. & Resolution - Mini DP: Max resolution 4096x2160@60Hz eDP1.3: Max resolution 4096x2160@60Hz Multiple Display - Dual Display Certifications Certification Information - CE FCC Class B Ethernet LAN Chipset - 1 x Intel I210AT/IT Gigabit Ethernet Ethernet Interface - 1 x 10/100/1000 Base-Tx GbE compatible LAN Port - 1 x RJ-45 Mechanical & Environmental Operating Temperature - 0~60°C, w/HDD/SSD, ambient with 0.5 m/s Air flow Elkhart Lake N/J Series CPU SKU -20~60°C, w/HDD/SSD, ambient with 0.5 m/s Air flow Elkhart Lake Atom x6000E Series CPU SKU Storage Temperature - -40°C ~ 75°C (-40°F ~ 167°F) Operating Humidity - 40°C @ 95% Relative Humidity, Non-condensing Weight - 0.30kg Power Requirement - DC in +12V ACPI - Single power ATX Support S0,S3, S4, S5 ACPI 5.1 Compliant Power Mode - AT / ATX mode Switchable Through Jumper Dimension (L x W) - 84mm (3.31") x 65mm (2.55") Software Support OS Information - Win 10 64bit Linux Ordering Information EZX-EHLP-J6412-A1R EZX-EHLP-J6413-A1R EZX-EHLP-X11E-A1R EZX-EHLP-X13E-A1R EZX-EHLP-X12RE-A1R Intel® Pentium®/Celeron®/Atom™ SoC BGA Processor 1.8"SBC MotherboardCONTACT US FOR VOLUME PRICING
Enquire for availability
Make an Enquiry
Avalue – Fanless Rugged Embedded System with 6 COMs
Avalue - Fanless Rugged Embedded System with 6 COMs
XProduct SKU: EMS-BYT-6COM
EMS-BYT-6COM Intel® Celeron®/Atom™ SoC Processor J1900/E3845 Fanless Rugged Embedded System with 6 COMs
Features
Onboard Intel® Celeron®/Atom™ J1900/E3845 BGA ProcessorOne 204-pin SODIMM Socket Up to 8GB DDR3L 1333MHz SDRAMRich I/O, 1 VGA, 1 LAN, 1 SIM Card Slot, 1 Swappable HDD, 1 Mic-In, 1 Line-In, 1 Line-Out, 1 12-bit GPIO, 1 SMBUS, 6 COM, 2 PS/2 for KB & MS, 2 Knockouts Antenna Mounting, 5 USBExpansion Slot Supports 2 Mini PCIe SlotFront Access Swappable 2.5"" Drive Bay, SIM CardRugged Design for Vibration & Shock ProtectionFanless Operating from -15 ~ 60°C & -40 ~ 75°CWide Range DC Power Input from 12 ~ 26VService Window, Easy to Install mSATA, Memory and Mini PCIe ModuleCONTACT US FOR VOLUME PRICING
Enquire for availability
Make an Enquiry
Avalue – Fanless Wide-Temperature Rugged Vehicle Transport Box PC
Avalue - Fanless Wide-Temperature Rugged Vehicle Transport Box PC
XProduct SKU: BOXED PC SOLUTION
Avalue offers comprehensive range of Industrial PC/ Computer, such as Embedded Computer, Transportation System, Rackmount System, ARM-based System in your different applications and environments.
Features
Compact System Ultra-compact, fanless, robust, and low power embedded computer family design for NUC board and 3.5" single board computers with Intel processors, featuring flexible I/O interface and different mounting options to meet the wide variety of applications. Modular System (IET) An innovative IET (Intelligent Expansion Technology) interface which offers flexibility to integrate multiple I/O w/o MOQ , or to develop the extension module in accordance with the project request Transportation System Avalue transportation systems/ transportation embedded computers are available for Vehicle, Railway and Marine that are a kind of indispensable component into smart city world. GPU & Edge AI Living in a booming AIoT World, Avalue GPU & Edge AI solutions are designed to bring the power of AI and Edge Computing to any industrial or embedded application. Provided with complete hardware solutions, we have everything you need to deploy smart applications. ARM-based System ARM based System series is a strong performance in a low power that specification for industrial applications.CONTACT US FOR VOLUME PRICING
Enquire for availability
Make an Enquiry
Avalue – imx8 sbc embeddded board
Avalue - imx8 sbc embeddded board
XProduct SKU: RSC-IMX8M
RSC-IMX8M is a 3.5-inch single-board computer that supports NXP® i.MX8M Quad ARM Cortex A53 Quad Core Up to 1.5GHz; Cortex-M4 core processor, providing an ultra-low power consumption with the TDP is less than 3.5W. Supports 2GB Onboard LPDDR4 Memory (expandable up to 4GB Max) for industry application, and 1GB Onboard LPDDR4 Memory (expandable up to 4GB Max) for consumer application. RSC-IMX8M is equipped with a wide array of I/O interfaces, including OTG USB 3.0 Type C (Data only), USB 3.0 Type-A, USB 3.0 Pin Header, HDMI, LVDS, and MIPI DSI, giving it high expandability. RSC-IMX8M also supports M.2 Key E Socket (For WIFI/BT), M.2 Key B Socket + SIM Socket (For LTE), Dual GLAN for multi-connection for IoT and AIOT related applications. RSC-IMX8M is providing Board Support Package (BSP) for Android 10 and Yocto Linux v2.5 operating systems to help customers quickly build Android and Linux solutions.
Features
NXP® i.MX8M Quad ARM Cortex A53 Quad Core Up to 1.5GHz; Cortex-M4 core processor System Memory 2GB RAM Storage Storage eMMC 8GB I/O USB Port OTG USB 3.0 Type C (Data only) USB 3.0 Type A USB 3.0 Pin Header COM Port Extend Board-1 (4 x RS232/485) Extend Board-2 (2 x RS232/485 , 1 x CAN Bus , 1 x GPIO) External I/O Connector 1 x USB 3.0 Type A(Vertical type) 2x RJ45 connector with indicate LED Industry Version:2pcs(Default) , Consumer Version:1pcs 1 x HDMI connector (Vertical type) 1 x USB 3.0 Type C 1 x Micro SD socket 1 x Hand Phone 1 x Reset 1 x Power LED (Green) Internal I/O Connector 1 x Front Panel connector 2 x MIPI CSI connector 1 x DC connector with lock Header 1 x TAG connector 1 x MIPI DSI connector 1 x LVDS connector 1 x Back Light connector 1 x I2C connector 1 x USB connector 1 x 2230 M.2 for WiFi/BT (PCIe& USB Channel) 1 x 3042 M.2 for 3G/4G Module (USB Only) 1 x SIM Socket connector 1 x 2x20P Header connector 1 x 1x2P Header (R) connector 1 x 1x2P Header (L) connector 1 x Line-Out Header with 12V out 1 x Mic-In Header connector Display Multiple Display Display (HDMI / LVDS / MIPI DSI) Certifications Certification Information CE FCC Class B Ethernet LAN Chipset LAN 1: Intel I210 LAN 2: AR8033 Ethernet Interface 2 x RJ45 Connectors for Dual Gigabit LAN Industry Version:2pcs(Default) Consumer Version:1pcs Mechanical & Environmental Operating Temperature Industry Operating temperature:-40~85 Degree (Default) Consumer Operating temperature:0~85 Degree Storage Temperature -40°C ~ 85°C Operating Humidity 0% ~ 90% Relative Humidity, Non-condensing Weight 0.16kg Power Requirement DC 12 ~ 24V Power Input Power Mode Terminal Block 2P power input connector Dimension (L x W) (146.05mm x 101.6mm) Software Support OS Information Linux Yocto Version 3.0 Android Version 10CONTACT US FOR VOLUME PRICING
Enquire for availability
Make an Enquiry
Avalue – Intel® Atom™ SoC processor J1900 Fanless Tiny System
Avalue - Intel® Atom™ SoC processor J1900 Fanless Tiny System
XProduct SKU: EPC-BYT2
Onboard Intel® Celeron® SoC ProcessorIntel® Valleyview D SoCOne 204-pin SODIMM Socket Up to 8GB DDR3L 1333MHz SDRAMRich I/O, 1 VGA, 1 HDMI,1 COM/2COM, 2 LAN, 4 USB, 2 Antenna mountingExpansion Slot Supports 2 Mini PCIe SlotWide Range DC Power Input from 12 ~ 26VFanless Operating from -10 ~ 45°CCompact Size, 175mm x 110mm x 40mmOptional Wall Mount Kit / VESA / DIN-RailSupports TPM 1.2 (Factory Option)
Features
System Information Processor Intel® Celeron® Processor J1900 (2M Cache, up to 2.42 GHz) System Memory One 204-pin SODIMM Socket Up to 8GB DDR3L 1333MHz SDRAM BIOS Information AMI uEFI BIOS, 64Mbit SPI Flash ROM Watchdog Timer H/W Reset, 1sec. ~ 65535sec./1sec.step H/W Status Monitor Monitoring System Temperature, Voltage with Auto Throttling Control SBC ECM-BYT2 Expansion Expansion 1 x Full Size Mini PCIe (mSATA supported) 1 x Half Size Mini PCIe Storage Storage 1 x mSATA 1 x 2.5” Drive Bay I/O USB Port 4 x USB (1 x USB 3.0, 3 x USB 2.0) COM Port 1 x RS-232/2 x RS232 (by order infomation) Antenna 2 x Antenna mounting Display Graphic Chipset Intel® HD Graphics Spec. & Resolution VGA Mode: 2560 x 1600 @ 60Hz HDMI Mode: 1920 x 1200 @ 60Hz Multiple Display Dual Display Certifications Certification Information CE, FCC Class A Ethernet LAN Chipset 2 x Realtek RTL8111E Gigabit Ethernet Ethernet Interface 10/100/1000 Base-Tx Gigabit Ethernet Compatible LAN Port 2 x RJ45 Power Requirement DC Input +12~26Vdc DC Input Connector Lockable DC Jack 2-Pin Terminal Block (Factory Option) ACPI Single Power ATX Support S0, S3, S4, S5 ACPI 3.0 Compliant Power Mode AT/ATX (ATX is the default setting) Adapter Input: 100 ~ 240Vdc/ 50 ~ 60Hz Output: 12V/5A AC-DC 60W Adapter Mechanical & Environmental Operating Temperature -10 ~ +45°C (w/mSATA & SSD), Ambient w/Air Flow (Factory Option:-10~+50°C) 0 ~ 40°C (32 ~ 104°F) (w/2.5" Drive Bay), Ambient w/Air Flow Storage Temperature -40 ~ 75°C (-40 ~ 167°F) Dimension (W x L x H) 175mm x 110mm x 40mm (W x D x H) Weight 960g Vibration Test With SSD: 1.5Grms, IEC 60068-2-64, Random, 5 ~ 500Hz, 30min/axis Shock Test With SSD: 10G, IEC 60068-2-27, Half Sine,11ms IP Rating 40 (Factory Option) Relative Humidity 0% ~ 90% Relative Humidity, Non-condensing Ordering Information Ordering Information EPC-BYT2-B1-1R Intel® Atom™ SoC processor J1900 Fanless Tiny System EPC-BYT2-B1-2R Intel® Atom™ SoC processor J1900 w/2COM Fanless Tiny System ACC-EPC-VESA-04R VESA 75 Mount Kit VESA Kit ACC-EPC-VESA-05R VESA 100 Mount Kit VESA Kit ACC-EPC-DINRACK-1R Din Rail KitCONTACT US FOR VOLUME PRICING
Enquire for availability
Make an Enquiry
Avalue – Intel® Celeron® J3455 Processor Pico-ITX Fanless Box PC
Avalue - Intel® Celeron® J3455 Processor Pico-ITX Fanless Box PC
XProduct SKU: ECS-APCL
1 x 204-pin DDR3L1600/1333MHz SO-DIMM socket, supports up to 8GB, 4GB installed as default.2 x USB 3.0, 2 x USB 2.01 x DP++, 1 x HDMI (Dual Display)1 x M.2 Type B 3042/2242/2260 supports SSD, 64GB installed as default.1 x M.2 Type A 2230 supports WiFi module2 x Intel i211AT Gigabit Ethernet2 x SMA connector (optional)60W Adapter (DC in 12V@5A)
Features
System Information Processor Intel® Celeron® J3455 Processor System Memory 1 x 204-pin DDR3L 1600MHz SO-DIMM, supports up to 8 GB, 4GB installed as default. Watchdog Timer H/W Reset, 1sec. ~ 65535min. and 1sec. or 1min./step H/W Status Monitor Monitoring CPU & System Temperature and Voltage SBC EPX-APLP Expansion Expansion 1 x M.2 Type A 2230 supports WiFi module Storage Storage 1 x M.2 Type B 3042/2242/2260 supports SSD, 64GB installed as default. I/O USB Port 2 x USB 3.0 2 x USB 2.0 COM Port 1 x RS-232 Other 1 x Power on/off Button w/ LED 2 x SMA Connector (Optional) Display Graphic Chipset Intel® Celeron® SoC Integrated Graphics Spec. & Resolution DP++: 4096 x 2160 @ 60Hz HDMI: 3840 x 2160 @ 30Hz, 2560 x 1600 @ 30Hz Multiple Display Dual Display Audio Audio Codec Realtek ALC897 Audio Interface Line-Out Ethernet LAN Chipset 2 x Intel i211AT GbE controller Ethernet Interface 10/100/1000 Base-Tx GbE compatible LAN Port 2 x RJ45 Power Requirement DC Input +12V DC Input Connector DC Jack (lockable) Power Mode ATX Adapter Input: 100 ~ 240Vac/ 50 ~ 60Hz Output: 60W Adapter (12V @ 5A) Mechanical & Environmental Operating Temperature -10°C ~ 50°C (32°F ~ 122°F) (w/SSD), ambient w/0.5 m/s air flow -10°C ~ 40°C (32°F ~ 104°F) (w/SSD), ambient w/0.2 m/s air flow Storage Temperature -20°C ~ 75°C (-4°F ~ 167°F) Operating Humidity 40°C @ 95% Relative Humidity, Non-condensing Dimension (W x L x H) 120.6 x 95.2 x 49.8 mm Weight 1Kg Mounting Kit L-bracket (Optional) Construction Aluminum + Metal Software Support OS Information Win 10, Linux Ordering Information Ordering Information ECS-APCL (ECS-APCL-3455-B1R) Intel® Celeron® J3455 Processor Pico-ITX Fanless Box PCCONTACT US FOR VOLUME PRICING
Enquire for availability
Make an Enquiry
Avalue – Intel® Elkhart Lake 3.5” Micro Module
Avalue - Intel® Elkhart Lake 3.5” Micro Module
XProduct SKU: ECM-EHL
Bottom Layer Soldered Processor -Single DRAM Socket, Max, Up to 32GB DDR4 -Triple Display, DP 1.4a , HDMI 2.0b, eDP 1.3 -Dual Expansion Slot, M.2 Key-B, M.2 Key-E -Dual Intel® Gigabit Ethernet, 2.5GbE, 1GbE -Wide Temperature, -40°C ~ 85°C -Wide DC-Input, +9~36Vdc
CONTACT US FOR VOLUME PRICING
Enquire for availability
Make an Enquiry
Avalue – Intel® Pentium®/Celeron®/Atom™ Processor Fanless Vehicle Telematics System
Avalue - Intel® Pentium®/Celeron®/Atom™ Processor Fanless Vehicle Telematics System
XProduct SKU: VMS-APL
Intel® Pentium®/Celeron®/Atom™ Processor Fanless Vehicle Telematics System
Features
Intel® Pentium®/Celeron®/Atom™ ProcessorOne 204-pin SODIMM Socket Up to 8GB DDR3L 1866MHz SDRAMRich I/O, 1 DP, 1 LVDS, 1 DC-Out, 1 8-bit GPIO, 1 M.2 SSD, 1 SD Card, 1 2.5" Swappable Drive Bay, 2 Line-out, 2 Mic-in, 2 LAN, 2 COM, 4 USB, 5 Antenna MountingOnboard u-box M8N concurrent GNS module (GPS/QZSS, GLONASS, BeiDou)Rugged Fanless Design Compliant with MIL-STD-810GPower Management and Low Voltage Protection DesignWake on RTC/SMS Via WWAN ModuleOptional CAN modules supports OBD II, SAE J1939 or J1708Wide Range DC Power Input from 9 ~ 36VFanless Operating from -20/40 ~ 70°CSupports TPM 1.2/2.0 (Factory Option), SD card(SD 3.0)Specifications
System Information Processor Intel® Pentium® Processor N4200 (2M Cache, up to 2.5 GHz) Intel® Celeron® Processor N3350 (2M Cache, up to 2.4 GHz) Intel® Celeron® Processor J3455 (2M Cache, up to 2.3 GHz) Intel Atom® x7-E3950 Processor (2M Cache, up to 2.00 GHz) Intel Atom® x5-E3940 Processor (2M Cache, up to 1.80 GHz) Intel Atom® x5-E3930 Processor (2M Cache, up to 1.80 GHz) System Memory 1 x 204-Pin DDR3L 1866MHz SO-DIMM up to 8 GB Watchdog Timer H/W Reset, 1sec. ~ 65535sec. H/W Status Monitor Monitoring CPU & System Temperature and Voltage SBC EBM-APLV Expansion Expansion 1 x Avalue 80-Pin IET Interface 2 x Full Size Mini PCIe (w/ SIM Slot) 1 x CANBus module Interface (UART) 1 x M.2 (2242/3042) B-Key (SATA) Storage Storage 1 x 2.5" Drive Bay (SATA III) 1 x M.2 (SATA III) 1 x SD (3.0) I/O USB Port 4 x USB 3.0 COM Port 2 x RS-232/422/485 (Jumper) GPIO 1 x 8-Bit GPIO (Digital Input) Input Voltage (Internal Type): 5VDC TTL (default) Input Voltage (Source Type): 0~30 VDC (Digital Output) Digital Output (Sink Type): 5VDC TTL (default), max current: 20mA Digital Output (Source Type): 0~30VDC, max current: 250mA CAN Bus CANbus modules supports OBDII, SAE J1939/J1708 (Factory Option) SIM Slot 2 x SIM Card Slot (External Accessible) Antenna 5 x Antenna Mounting with Dust Cover GPS Chipset Onboard u-blox NEO-M8N module supports GPS/ Gloness/ QZSS/ Galileo/ Beidou Sensitivity Industry leading –167 dBm navigation sensitivityProduct variants to meet performance and cost requirementsCombines low power consumption and high sensitivity Display Graphic Chipset Processor Graphics Intel® HD Graphics 505 (N4200, E3950) Intel® HD Graphics 500 (E3950, E3940, E3930) Spec. & Resolution DP: Max. Resolution 4096x2160 @ 60Hz LVDS: Max. Resolution 1920x1200 @ 60Hz Multiple Display Dual Display Audio Audio Codec Realtek ALC888S supports 2.1-CH Audio Interface 2 x Mic-In, 2 x Line-Out Certifications Certification Information CE, FCC Class B, e13 Mark, ISO7637-2, IP50 Rating Ethernet LAN Chipset 2 x Intel® I211AT Ethernet Interface 10/100/1000 Base-Tx GbE compatible LAN Port 2 x RJ-45 Power Requirement DC Input Typical 12/24 Vdc ( +9~ 36V ) DC Input Connector 3-Pin Terminal Block DC Output 12Vdc/6A DC Output Connector 2-Pin Terminal Block ACPI Single Power ATX Support S0, S3, S4, S5 ACPI 5.0 Compliant Power Mode Vehicle Power Mode (Default Setting) Industrial PC Power Mode supports AT/ATX Mechanical & Environmental Operating Temperature N4200/ N3350/J3455 With extended temperature peripherals: -20°C ~ 70°C (-4°F ~ 158°F) with air flow E3950/ E3940/ E3930 With extended temperature peripherals: -40°C ~ 70°C (-40°F ~ 158°F) with air flow Storage Temperature -40°C ~ 85°C (-40°F ~ 185°F) Operating Humidity 40°C @ 95% Relative Humidity, Non-condensing Dimension (W x L x H) 9.45” x 7.3” x 2.44” (239mm x 186mm x 62mm) Weight 2.6kg (system) 3.2kg (w/package) Vibration Test Operating with SSD : MIL-STD-810G, Method 514.6, Category 4, common carrier US highway truck vibration exposure Storage with SSD : MIL-STD-810G, Method 514.6, Category 24, minimum integrity test Shock Test Operating with SSD : MIL-STD-810G, Method 516.6, Procedure I, functional shock=20G Non-Operating with SSD : MIL-STD-810G, Method 516.6, Procedure V, crash hazard shock test=75G Mounting Kit Wall Mount kit (Standard) Construction Aluminum + Metal Software Support OS Information Win 10, Linux Android (by request) Ordering Information Ordering Information VMS-APL-N42-B1-1R Intel® Pentium® Processor N4200 Fanless Vehicle Telematics System VMS-APL-N33-B1-1R Intel® Celeron® Processor N3350 Fanless Vehicle Telematics System VMS-APL-J34-B1-1R Intel® Celeron® Processor J3455 Fanless Vehicle Telematics System VMS-APL-E50-B1-1R Intel® Celeron® Processor E3950 Fanless Vehicle Telematics System VMS-APL-E40-B1-1R Intel® Celeron® Processor E3940 Fanless Vehicle Telematics System VMS-APL-E30-B1-1R Intel® Celeron® Processor E3930 Fanless Vehicle Telematics SystemCONTACT US FOR VOLUME PRICING
Enquire for availability
Make an Enquiry
Avalue – Marine System Onboard 6th Gen Intel® Core™ SoC i7/i5/i3/Celeron BGA Processor
Avalue - Marine System Onboard 6th Gen Intel® Core™ SoC i7/i5/i3/Celeron BGA Processor
XProduct SKU: EMS-SKLU-MARINE
EMS-SKLU-Marine 6th Gen Intel®Core™ Processor i7/i5/i3/Celeron, Marine Fanless Rugged Embedded System with 4 COM Isolations
Features
Onboard 6th Gen Intel® Core™ SoC i7/i5/i3/Celeron BGA ProcessorOne 260-pin SODIMM Socket Up to 16GB DDR4 2133MHz SDRAM4 COM port support 2.5KV Isolation ProtectionExpansion Slot Supports 1 Mini PCIe Slot, 1 M.2, 1 IET InterfaceFanless Operating from -20 ~ 60°C, Support IP50Power Input :Typical 12/24Vdc ( +9 ~ +36V )Supports Intel® iAMT 11.0, TPM2.0, Turbo Boost Technology, vPro, Wake on LAN, RAID 0/1Service Window, Easy to Install M.2, Memory and Mini PCIe ModuleIEC EN60945 CertifiedCONTACT US FOR VOLUME PRICING
Enquire for availability
Make an Enquiry
Avalue – Mini ITX 11th Gen Intel® CoreTM / Celeron® BGA Processor Embedded Industrial motherboards
Avalue - Mini ITX 11th Gen Intel® CoreTM / Celeron® BGA Processor Embedded Industrial motherboards
XProduct SKU: EMX-TGLC
EMX-TGLC
Intel® Core oC i7/i5/i3 & Celeron BGA Processor Thin Mini ITX Motherboard a Thin Mini ITX board with 11th Gen Intel® Core i3/i5 and Celeron® BGA Consumer SKU Processor, it is a Dual Gigabit LAN and firstly introduced Quad display industrial motherboard suitable application for Network devices, NAS Server, Media Center, Industrial control systems and other embedded applications.Features
:- Onboard 11th Gen. Intel® Core™ SoC i5/i3 & Celeron® BGA Processor (Support Consumer CPU SKU) :- 2 x 260-pin DDR4 3200 MHz SO-DIMM supports up to 64GB (non ECC only) :- 2 x DP++, 1 x LVDS, 1 x eDP (Quadruple independent displays) :- 1 x Intel® I226LM 2.5 Gigabit Ethernet :- 1 x Intel® I219LM Gigabit Ethernet PHY :- Realtek ALC897 co-lay ALC888S (Default: Realteck ALC897) :- TI TPA3113D2PWP Stereo Class-D 6W x 2 Audio Amplifier :- 1 x M.2 Type B 3042/3052/2242/2260/2280 (with 1 x PCI-e x1 (default) or SATA, USB 3.0 with 1 x SIM card slot, support WWAN+GNSS or NVMe SSD :- *SATA 2 share with M.2 key B SATA :- 1 x M.2 Key E 2230 support WiFi module and CNVi (1 x PCI-e x1 & USB 2.0 Signal) :- 1 x PCI-e x4 slot support PCI-2 x2(Gen3) device :- GPIO 16bit :- Onboard NuvoTon NPCT754AADYX support TPM 2.0 :- Support Line-out & Mic-in & Front audio pin-header :- DC in +12V~24VSpecifications
System Information
Processor Intel® Core™ i5-1135G7 (up to 4.2GHz, quad-core, 8M Cache, TDP: 15W Intel® Core™ i3-1115G4 (up to 3.0GHz, dual-core, 6M Cache, TDP: 15W Intel® Celeron® 6305E (up to 1.8GHz, dual-core, 4M Cache, TDP: 15W System Memory 2 x 260-pin DDR4 3200 MHz SO-DIMM supports up to 64GB (non ECC only) I/O Chipset EC iTE IT8528E BIOS Information AMI uEFI BIOS, 256Mbit SPI Flash ROM Watchdog Timer H/W Reset: 1sec. ~ 65535sec./min. and 1sec. or 1min./step H/W Status Monitor CPU temperature monitoring Voltages monitoring CPU fan speed control TPM Onboard NuvoTon NPCT754AADYX support TPM 2.0Expansion
Expansion 1 x M.2 Type B 3042/3052/2242/2260/2280 (with 1 x PCI-e x1 (default) or SATA, USB 3.0 with 1 x SIM card slot, support WWAN+GNSS or NVMe SSD *SATA 2 share with M.2 key B SATA 1 x M.2 Key E 2230 support WiFi module and CNVi (1 x PCI-e x1 & USB 2.0 Signal) 1 x PCI-e x4 slot support PCI-e x2(Gen3) device *Only support 25W Slot, +V12A total current is 8.7A.I/O
USB Port 3 x USB 3.1 Gen2, 1 x USB 3.1 Gen1 at I/O 4 x USB2.0 by pin header COM Port 4 x RS232 2 x RS232/422/485 SATA 1 x SATA Power 2 x SATA III DIO 1 x 16-bit GPIODisplay
Graphic Chipset Intel® 12th Generation CPU integrated Spec. & Resolution DP1+DP2 (DP1.4): Max: 7680 x 4329@60 Hz Single DP port (2021/2 Lab test): 5120 x 2160 @60 Hz, DVT check Max: 7680 x 4329@60 Hz Note: This resolution is actual test result. Intel resolution as below: 2 x DP++ : 1920 x 1080@60 Hz LVDS: 1920 x 1080 Dual channel 18/24-bits LVDS (Chrontel CH7511B eDP to LVDS) eDP 4096 x 2304@60 Hz *2 x DP++, LVDS, eDP (Quadruple independent displays) Multiple Display 2 x DP++/1 x LVDS/1 x eDP (Quadruple independent displays) LVDS 2CH 18/24bits LVDS 1920 x 1080 Chrontel. CH7511B eDP to LVDS ConverterAudio
Audio Codec Realtek ALC897 co-lay ALC888S Audio Interface Support Line-out & Mic-in & Front audio pin-header Audio Amplifier 2 x Stereo Class-D 6W Audio AmplifierEthernet
LAN Chipset 1 x Intel® I226LM 2.5 Gigabit Ethernet 1 x Intel® I219LM Gigabit Ethernet PHY Ethernet Interface 10/100/1000 Base-Tx GbE compatible LAN Port 4 x RJ45Mechanical & Environmental
Operating Temperature Intel@ standard CPU SKU support: 0~60C Storage Temperature -40 ~ 75°C (-40 ~ 167°F) Operating Humidity 40°C @ 95% Relative Humidity, Non-condensing Weight 0.88lbs (0.4Kgs) Power Requirement +12V~24V Power Mode AT/ATX Dimension (L x W) 6.69” x 6.69” (170mm x 170mm)Software Support
OS Information Win10 64bit LinuxCONTACT US FOR VOLUME PRICING
Enquire for availability
Make an Enquiry
Avalue – OFP-07W33 7″ WXGA PCAP Multi-Touch Fanless Open Frame Panel PC with Intel® Celeron® N3350/J3455
Avalue - OFP-07W33 7" WXGA PCAP Multi-Touch Fanless Open Frame Panel PC with Intel® Celeron® N3350/J3455
XProduct SKU: OFP-07W33
7" WXGA PCAP Multi-Touch Fanless Open Frame Panel PC with Intel® Celeron® N3350/J3455 Processor
Features
:- 7"WXGA Open frame panel PC with PCAP Touch :- Onboard Intel® Celeron® N3350/J3455 SoC BGA Processor :- 1x 204-pin DDR3L 1866/1600/1333 MHz SO-DIMM supports up to 8GB :- 1x HDMI, 2x GbE LAN, 4x USB 3.2(Gen1x1, 5Gbps), 2x USB2.0 (pin header) :- 1x RS-232, 1x RS-232/422/485 (pin header) :- 1x Full Size Mini-PCIe support mSATA, 1x Half Size Mini-PCIe for option WIFI/BT :- 1x 8bit GPIO (pin header) :- Slim & Strength Design :- Fanless Operation from 0° ~ 45°C :- Wide Voltage Input +12 ~ 26VdcSpecifications
System Information
Processor Onboard Intel® Celeron® N3350/ J3455 SoC BGA Processor System Memory Default with 4GB DDR3L Memory Option supports up to 8GB DDR3L 1866/1600/1333 MHz SO-DIMM I/O Chipset EC iTE IT8528 BIOS Information AMI 128Mbit SPI BIOS Watchdog Timer H/W Reset: 1sec. ~ 65535sec./min. and 1sec. or 1min./step H/W Status Monitor Monitoring System Temperature and Voltage with Auto Throttling Control CPU Cooler (Type) Fanless Heatsink Board ECM-APL2-B1Expansion
Expansion 1 x Full size Mini PCIe Supports mSATA 1 x Half size Mini PCIe for option Wi-Fi/BTStorage
Storage Default with 64GB mSATA (Support up to 512GB)Panel
LCD Size 7", 16:10 Display Type WXGA Resolution 1280 x 800 Pixel pitch 0.03925(H) x 0.11775(V) Luminance 300 cd/m² Contrast ratio 900 Viewing angle 89 (U), 89 (D), 89 (L), 89 (R) Response time 30 ms Backlight LED Touch Type Projective Capacitive Multi-Touch supports up to 10 points Touch Light Transmission 89 % Touch Controller EETII/O
USB Port 4 x USB 3.2 (Gen1x1, 5Gbps) 2 x USB 2.0 (option by pin header) COM Port 1 x RS-232 1 x RS-232/422/485 option by pin header DIO 8-bit GPIO option by pin header HDMI 1 x HDMI 1.4b: Max. Resolution 3840 x 2160 @ 30HzDC In/Out Characteristics
Power Type AT/ATXAudio
Audio Codec Realtek ALC888S supports 5.1-CHCertifications
Certification Information CE, FCC Class AEthernet
LAN Chipset 2 x Intel® I211AT Ethernet Interface 10/100/1000 Base-Tx GbE compatible LAN Port 2 x RJ45Mechanical & Environmental
Operating Temperature 0°C ~ 45°C Storage Temperature -10°C ~ 50°C Operating Humidity 40°C @ 95% Relative Humidity, Non-condensing Dimension (W x L x H) 183.1 x 115.85 x 48.1 mm Weight 700g Vibration Test With mSATA : 1.5Grms, IEC 60068-2-64, Random, 5 ~ 500Hz, 0.5hr/axis Shock Test Operating with mSATA : IEC 60068-2-27 testing procedures, 10G for operation mode Mounting Kit Option with Flush / Panel Mounting kits Power Requirement +12V~26V DC in Lockable DC Jack Power Mode AT/ATX System Fan Fanless Relative Humidity 40°C @ 95% Relative Humidity, Non-condensing Fanless Yes Drop ISTA 2A, IEC-60068-2-32 Test:EdSoftware Support
OS Information Windows 10 Ubuntu 16.04 Android x86 8.1Ordering Information
Ordering Information OFP-07W33-345-A1R 7" WXGA Multi Touch Open Frame Panel PC / Intel Celeron J3455, 4GR,64GB mSATA,4USB3,COM,2LAN,HDMI without adapter OFP-07W33-335-A1R 7" WXGA Multi Touch Open Frame Panel PC / Intel Celeron N3350, 4GR,64GB mSATA,4USB3,COM,2LAN,HDMI without adapter ACC-ADP-060N-08R AC/DC adapter 12V/5A 90 degree Screw Type E1702031833R USA Power Cord E1702031000R EU Power Cord E1702031834R Japan Power Cord E1702031830R UK Power Cord E1702031831R Australia Power CordCONTACT US FOR VOLUME PRICING
Enquire for availability
Make an Enquiry
