Products
Showing 1–18 of 183 results
Avalue - 10" Open Frame Panel PC
XProduct SKU: ACC-ADP-065N-01R
Enquire for availability
Make an EnquiryAvalue - 10" Open Frame Panel PC
XProduct SKU: BCC-OFT-BKT10-01R
In stock
Make an EnquiryAvalue - 10" Open Frame Panel PC
XProduct SKU: BCC-OFT-PMK10-01R
Enquire for availability
Make an EnquiryAvalue - 10" Open Frame Panel PC
XProduct SKU: BCC-OFT-WMK10-02R
Enquire for availability
Make an EnquiryAvalue - 10" PoE PCAP Open Frame Panel PC
XProduct SKU: OFT-10W02-BV38C-2R
-Intel® Atom™ x5-Z8300 / Z8350 Processor: 1.44GHz -2GB RAM -32GB eMMC -PCAP Touch -10/100/1000 Ethernet (PXE Boot) -Touch board interface (Power/ Brightness/ Volume/ LED) -16Bit programmable GPIO -RS232(TX/RX) or RS485 -Typical DC 19V Input, Optional 12V & 24V support -Optional Powered LAN 802.3AT (10" only)
Features
- Intel® Atom™ x5-Z8300 / Z8350 Processor: 1.44GHz - 2GB RAM - 32GB eMMC - PCAP Touch - 10/100/1000 Ethernet (PXE Boot) - Touch board interface (Power/ Brightness/ Volume/ LED) - 16Bit programmable GPIO - RS232(TX/RX) or RS485 - Typical DC 19V Input, Optional 12V & 24V support - Optional Powered LAN 802.3AT (10" only)Specifications
System Information
Processor Intel® Atom™ x5-Z8300/Z8350 Processor: 1.44GHz System Memory 2GB DDR3L RAM Other 802.11 b/g/n WiFiStorage
Storage 32GB eMMCI/O
External I/O Connector 2 x USB 2.0 1 x micro USB Client(Android only, not support at the moment) 1 x 10/100/1000 Ethernet 1 x HDMI 1 x Head phone jack 1 x Micro SD slot 1 x DC jack Internal I/O Connector 1 x RS232(TX/RX) or RS485 1 x 16 bit GPIO interface 1 x USB interface 1 x eDP & Dual channel 24bit LVDS 1 x backlight control & power 2 x speaker interface (1.2W stereo) 1 x A-MIC interface 1 x Touch Button connector 1 x DC input 4pin header 1 x I2C interfaceDisplay
Multiple Display Windows support extended modeMechanical & Environmental
Operating Temperature 0°C ~ 40°C Storage Temperature -10°C ~ 60°C0 Operating Humidity 40°C @ 95% Relative Humidity, Non-condensing Dimension (L x W) 252 x 166 x 38 mm Weight 1.18kg Power Requirement DC input 12 ~ 24V Power Mode DC Jack, DC input 4pin header, optional Powered LAN 802.3ATSoftware Support
OS Information Windows 10 IoT (64 bit)Ordering Information
Ordering Information OFT-10W02-32GB eMMC OFT-10W02-32GB eMMC w/ Powered LANCONTACT US FOR VOLUME PRICING
In stock
Make an EnquiryAvalue - 12-22" IP65-IP69K Rated Front and Rear PCAP Multi Touch Panel PC
XProduct SKU: STAINLESS STEEL PANEL PC
12 to 22"Fully IP Rated Fanless Touch Panel PC with Intel Atom Quad Core CPU's. Supports up to 8GB of memory along with a choice of storage options. They can operate in temperatures between 0°C ~ 40°C & can also be VESA mounted. Fully IP rated IO
Features
CONTACT US FOR VOLUME PRICING
Enquire for availability
Make an EnquiryAvalue - 12" PCAP Panel PC
XProduct SKU: OFT-1202
Intel® Atom™ x5-Z8350 -2GB RAM 32GB eMMC -PCAP Touch10/100/1000 -EthernetRS232(TX/RX) and RS485 - DC 12~24V Input
CONTACT US FOR VOLUME PRICING
Enquire for availability
Make an EnquiryAvalue - 15.6 Fanless Panel PC
XProduct SKU: ARC-15W33
5.6” WXGA LCD with PCAP Multi-TouchOnboard Intel® Celeron® N3350 SoC BGA Processor1 x 204-pin DDR3L SODIMM Socket, Supports Up to 8GB DDR3L 1600MTs SDRAMRich I/Os, 2 LAN, 2 COM, 4 USB, SIM Card Slot, Swappable Drive Bay, Speaker out for Flexible Expansion ModulesRugged Design for Vibration & Shock Protection, Cableless DesignFanless Operation from -10 ~ 50°CWide Range DC Power Input from +9 ~ 36VdcService Window, Easy to Install Memory ModuleFront panel: IP65, Rear: IP41(except I/O)TPM2.0 (optional)
CONTACT US FOR VOLUME PRICING
Enquire for availability
Make an EnquiryAvalue - 15.6" 1920 X 1080 PCAP Multi Touch Panel PC Windows / Linux / Android
XProduct SKU: SID-15W03-5005-A1R-P
15.6” TFT-LCD, WXGA, 1920 x 1080Projective Capacitive Multi-TouchIP65 Front PanelIntel Atom Z8350F 1.44GHz Processor2GB/4GB DDR3L Memory on board32GB/64GB eMMC on board10/100Mbps Fast EthernetWiFi IEEE802.11 ac/b/g/n on boardWide range DC 12~24V DC inputWindows 10 or Linux supported
Features
System Information Processor Intel Atom x5-8350 Quad Core CPU 1.44 GHz, up to 1.92 GHz System Memory 2GB/4GB DDR3L on board Storage Storage 32GB/64GB eMMC on board External I/O USB Port 1 x USB 3.0, 2 x USB 2.0 Video Port 1 x HDMI 1.4 output Audio Port 1 x Line out LAN Port 1 x Fast Ethernet(10/100Mbps) Wireless LAN Antenna 1 x SMA type connector Panel LCD Size 15.6" LCD Panel TFT-LCD Display Type FHD Resolution 1920x1080 Pixel pitch 0.1792 x 0.1792mm Luminance 220 cd/m2(typ) Contrast ratio 800 Viewing angle 89 (U), 89 (D), 89 (L), 89 ( R) Response time 7ms Backlight LED Touch Type Projective Capacitive Touch Light Transmission 86% Data Communication WLAN 802.11 ac/b/g/n Bluetooth Bluetooth 5.0 Certifications Certification Information CE/FCC Part 15, Subpart B Power Requirement DC Input DC 12~24V Input Power Mode AT mode(Default) Adapter Input: 100~240 Vac/50~60 Hz, Output: 60W Adapter (12V @ 5A Adapter) Mechanical & Environmental Operating Temperature 0°C ~ 40°C (32°F ~ 104°F) Storage Temperature -20°C ~ 60°C (-4°F ~ 140°F) Operating Humidity 40°C @ 95% Relative Humidity, Non-condensing Weight 3.7kg IP Rating Front IP65 Mounting Kit 100 x 100mm Dimensions(W x L x D) 391.2 x 239.2 x 48.1mm Power Requirement 12-24V DC Input Construction Metal Software Support OS Information Windows 10 2019 / Linux(TBA)CONTACT US FOR VOLUME PRICING
Enquire for availability
Make an EnquiryAvalue - 15.6" Industrial Panel PC with Rockchip RK3288
XProduct SKU: SID-15WR1
15.6" Semi Industrial Panel PC with Rockchip RK3288 SoC
Features
-15.6" TFT-LCD, WXGA, 1920 x 1080 -Projective Capacitive Multi-Touch -IP65 Front Panel -RockChip RK3288 Cortex-A17 Quad Core 1.6GHz -2GB DDR3L on board16GB eMMC on board -1 x 802.11 b/g/n Wireless LAN and Bluetooth 4.0 -1 x 10/100/1000 Ethernet -2 x USB Type A, 1 x HDMI output, 1 x Head phone jackWide range - DC 12~24V DC inputCONTACT US FOR VOLUME PRICING
Enquire for availability
Make an EnquiryAvalue - 15.6" PCAP Panel PC
XProduct SKU: OFT-15W03-P
OFT-15W03
15.6" Open Frame Tablet - Intel® Atom - Quad Core Z8350 1.44GHz - 2GB RAM or 4GB RAM32GB or 64GB eMMC - PCAP touch - 10/100 Ethernet M.2 B-Key(3042) slot802.11 b/g/n/ac - WIFISupport - Windows 10 / Ubuntu OSD - C12~24V inputFeatures
- LCD Size 15.6" - LCD Panel TFT LCD - Display Type Full HD - Resolution 1920x1080 - Pixel pitch 179.25(H) x 179.25(V) - Luminance 220 cd/m² - Contrast ratio 800 - Viewing angle 85 (U), 85 (D), 85 (L), 85 ( R) - Response time 30ms - Backlight LED - Touch Type Projective Capacitive - Touch Light Transmission 85%CONTACT US FOR VOLUME PRICING
Enquire for availability
Make an EnquiryAvalue - 17" IP Rated Rugged Panel PC
XProduct SKU: LPC-1709(STD)
ntel® Atom™ E3845 1.91GHz CPUOne 204-pin DDR3L SODIMM Socket Supports Up to 8GB DDR3L 1333 SDRAM1 CF, 2 USB, 1 COMDual Intel I210IT Gigabit LANWide Voltage +12V ~ +26V Input, ErP PowerBacklight Controlled by PWMIP65 Compliant Front PanelTimer-Power-On
Features
Spec System Information Processor Intel® Atom™ E3845 4-Core 1.91GHz processor System Memory 1 x 204-Pin DDR3L 1333MHz SO-DIMM up to 8 GB I/O Chipset EC ITE IT8528E Watchdog Timer H/W Reset, 1sec. ~ 65535sec./1sec.step H/W Status Monitor Monitoring CPU & System Temperature and Voltage SBC EBM-BYT Expansion Expansion 1 x Mini PCIe Support mSATA 1 x Mini PCIe Supports SIM Card Storage Storage 1 x CompactFlash Type I/II Socket 1 x 2.5" Drive Bay Panel LCD Size 17", 4:3 Display Type SXGA Resolution 1280x1024 Pixel pitch 0.264mm(H) x 0.264mm(V) Luminance 350 cd/m2 Contrast ratio 800 Viewing angle 80 (U), 80 (D), 85 (L), 85 (R) Response time 30 ms Backlight LED Touch Type 5 Wires resistive Touch Light Transmission 80% Touch Controller Onboard USB touch (EETI) I/O USB Port 1 x USB 3.0 1 x USB 2.0 COM Port 1 x RS-232/422/485 (BIOS) SATA 1 x SATA II Other 1 x HDMI 1 x Knockouts for Antenna Mounting Display Graphic Chipset Intel® Valleyview SoC integrated Graphics Supports dual display Spec. & Resolution HDMI:Max. resolution 1920x1200@ 60Hz Audio Audio Codec Realtek ALC888S Audio Interface Line-Out Speaker Output 2 x 1W Certifications Certification Information CE / FCC Class B Ethernet LAN Chipset 2 x Intel® I210IT Ethernet Interface 10/100/1000 Base-Tx GbE compatible LAN Port 2 x RJ-45 Power Requirement DC Input +12V ~ +26V DC Input Connector Lockable DC Jack Power Mode AT/ATX (ATX is default setting) Adapter Input: 100 ~ 240Vac/ 50 ~ 60Hz Output: 60W Adapter (12V @ 5A Adapter) Mechanical & Environmental Operating Temperature -20°C ~ 60°C (-4°F ~ 140°F) Storage Temperature -30°C ~ 70°C (-22°F ~ 158°F) Operating Humidity 0% ~ 90% Relative Humidity, Non-condensing Dimension (W x L x H) 382 x 320 x 58.8 mm Weight 5 Kgs Vibration Test With SSD/mSATA : 1.5Grms, IEC 60068-2-64, Random, 5 ~ 500Hz, 30min/axis Shock Test With CF/SSD : 10Grms, IEC 60068-2-27, Half Sine, 11ms System Fan Fanless Construction - Front Silver Aluminum Construction - Rear Black Software Support OS Information Win 7 Win 8 Linux Ordering Information Ordering Information LPC-1709-384-A4R Intel Atom E3845 1.91GHz CPU/ 4G DDR3L/2GLAN/COM/SPK/12~26V input/12V Adaptor LPC-1709-WMB-A4R Intel Atom E3845 1.91GHz CPU/ 4G DDR3L/2GLAN/COM/SPK/ Back Panel Mount/ 12~26V input/12V Adaptor ACC-LPC-WIFI-01R MPCIE WIFI-Kit for LPC Series(half-card) Antenna/Cable/BT4.0/802.11a/b/g/n/ac ACC-ARM-D1R VESA STAND, 75mm & 100 mm ACC-ARM-D19R VESA STAND, 75mm & 100 mm ACC-LPC-17-PMT-01R Front Panel Mount Kit for LPC-17 Series, w/o IP-65 ACC-LPC-17-PMT-02R Back Panel Mount Kit for LPC-17 Series, w/IP-65CONTACT US FOR VOLUME PRICING
Enquire for availability
Make an EnquiryAvalue - 21" FHD PCAP Panel PC
XProduct SKU: OFT-21W33
21.5” Full-HD Open frame panel PC with PCAP Touch -Onboard Intel® Celeron® J3455 SoC BGA Processor (2M Cache, up to 2.30 GHz) -2 x 204-pin DDR3L 1600 & 1333MHz SO-DIMM supports up to 16GB2x GbE LAN, -4 x USB 3.0, Line-out, Mic-in, 1 x COM, DP++, HDMI/DPOption for 4 x COM, 4 x USB2.0, -16-bit GPIO with DB9 connector -Slim & Strength Design -Fanless Operation from 0° ~ 45°C -Wide Voltage Input +12 ~ 24Vdc -Option for Wi-Fi & BT function -Option for Infineon SLB9665 TPM 2.0
Specifications
21.5” Full-HD Open frame panel PC with PCAP TouchOnboard Intel® Celeron® J3455 SoC BGA Processor (2M Cache, up to 2.30 GHz)2 x 204-pin DDR3L 1600 & 1333MHz SO-DIMM supports up to 16GB2x GbE LAN, 4 x USB 3.0, Line-out, Mic-in, 1 x COM, DP++, HDMI/DPOption for 4 x COM, 4 x USB2.0, 16-bit GPIO with DB9 connectorSlim & Strength DesignFanless Operation from 0° ~ 45°CWide Voltage Input +12 ~ 24VdcOption for Wi-Fi & BT functionOption for Infineon SLB9665 TPM 2.0CONTACT US FOR VOLUME PRICING
Enquire for availability
Make an EnquiryAvalue - 3.5" 8th Gen Intel® Whiskey Lake
XProduct SKU: ECM-WHL
Bottom Layer Soldered -Intel® CoreTM/Celeron® BGA Processor -nItel® UHD Graphics 620/610 -Dual DRAM Socket, Max. Up to 64GB DDR4 2400MHz -Triple Display (Dual HDMI, LVDS)HDMI w/CEC Control (Factory Option) -Dual Expansion Slot, 2-M.2 -Dual Gigabit Ethernet, HD Audio Code -Support TPM 2.0, RAID 0/1
Features
-Intel® Core™ i7-8665UE Processor (8M Cache, up to 4.40 GHz) -Intel® Core™ i5-8365UE Processor (6M Cache, up to 4.10 GHz) -Intel® Core™ i3-8145UE Processor (4M Cache, up to 3.90 GHz) -Intel® Celeron® Processor 4305UE (2M Cache, 2.00 GHz)CONTACT US FOR VOLUME PRICING
Enquire for availability
Make an EnquiryAvalue - 6th Gen Intel®Core™ Processor i7/i5/i3/Celeron Fanless Rugged Embedded System
XProduct SKU: EMS-SKLU-HDMI
Onboard 6th Gen Intel® Core™ SoC i7/i5/i3/Celeron BGA ProcessorOne 260-pin SODIMM Socket Up to 16GB DDR4 2133MHz SDRAM1xHDMI,1xDP,4xLAN,3xCOM1,4xUSB 3.0,2xUSB2.0,1xMulti-Function Port (1xGPIO,1xCOM2,1xAudio,1xSMBus,2xPS2)Expansion Slot Supports 1 Mini PCIe Slot, 1 M.2, 1 IET InterfaceFront Access Swappable 2.5" Drive Bay, 2 SIM CardRugged Design for Vibration & Shock ProtectionFanless Operating from -20 ~ 60°C, Support IP50 Power Input: Typical 12/24 Vdc ( +9~ 32V ) Supports Intel® iAMT 11.0, TPM2.0 , Turbo Boost Technology, vPro, Wake on LAN, RAID 0/1Service Window, Easy to Install M.2, Memory and Mini PCIe Module
Features
System Information Processor 6th Gen Intel® Core™ i7-6600U, 2-Core, 2.6GHz processor 6th Gen Intel® Core™ i5-6300U, 2-Core, 2.4GHz processor 6th Gen Intel® Core™ i3-6100U, 2-Core, 2.3GHz processor 6th Gen Intel® Celeron® 3955U, 2-Core, 2.0GHz processor System Memory 1 x 260-Pin DDR4 2133MHz SO-DIMM up to 16 GB Watchdog Timer H/W Reset, 1sec. ~ 65535sec. H/W Status Monitor Monitoring CPU & System Temperature and Voltage SBC EBM-SKLUS + EBM-BYTS DB-A Expansion Expansion 1 x Avalue 80-Pin IET Interface 1 x Mini PCIe 1 x M.2 (2242/3042) B-Key, supports SATA/ PCIex1/ USB3.0 Storage Storage 1 x 2.5" Drive Bay 1 x M.2 (SATA) I/O USB Port 4 x USB 3.0 2 x USB 2.0 COM Port 4 x RS-232/422/485 (Jumper), supports auto-flow GPIO 1 x 12bit GPIO DIO 1 x 12bit GPIO Other 2 x SIM Card Slot 1 x SMBus 2 x PS2/ KB & MS 2 x Knockouts for Antenna Mounting Display Graphic Chipset Intel® Skylake SoC integrated Graphics Spec. & Resolution DP: Max. resolution 4096x2304 @ 60Hz HDMI: Max. resolution 4096x2304 @ 24Hz Audio Audio Codec Realtek ALC888S supports 2.1-CH Audio Interface Mic-In, Line-In and Line-Out Ethernet LAN Chipset 1 x Intel® I211AT 1 x Intel® I219LM Ethernet Interface 10/100/1000 Base-Tx GbE compatible LAN Port 4 x RJ-45 Power Requirement DC Input Power input: Typical 12/24Vdc(+9V ~ +32V) TVS component for surge protection Reverse current/voltage protection DC Input Connector 3-Pin Terminal Block ACPI Single Power ATX Support S0, S3, S4, S5 ACPI 5.0 Compliant Power Mode AT/ATX (ATX is default setting) Adapter Optional AC-DC Adapter Mechanical & Environmental Operating Temperature (w/SSD), ambient w/ air flow -20°C ~ 60°C (-4°F ~ 140°F) (w/HDD), ambient w/ air flow 0°C ~ 40°C (32°F ~ 104°F) Storage Temperature -40°C ~ 75°C (-40°F ~ 167°F) Operating Humidity 40°C @ 95% Relative Humidity, Non-condensing Dimension (W x L x H) 9.45" x 5.96" x 2.36" (240mm x 151.5mm x 60mm) Vibration Test With SSD : 5Grms, IEC 60068-2-64, Random, 5 ~ 500Hz, 1hr/axis Shock Test With SSD : 50Grms, IEC 60068-2-27, Half Sine, 11ms Mounting Kit Wall Mount kit (Standard) Construction Aluminum + Metal Software Support OS Information Win 10 / Win 8.1 / Win 7 / Linux Ordering Information Ordering Information EMS-SKLU-66-B1-6R 6th Gen Intel®Core™ Processor i7-6600U Fanless Rugged Embedded System with HDMI EMS-SKLU-63-B1-6R 6th Gen Intel®Core™ Processor i5-6300U Fanless Rugged Embedded System with HDMI EMS-SKLU-61-B1-6R 6th Gen Intel®Core™ Processor i3-6100U Fanless Rugged Embedded System with HDMI EMS-SKLU-39-B1-6R 6th Gen Intel®Celeron Processor 3955U Fanless Rugged Embedded System with HDMICONTACT US FOR VOLUME PRICING
Enquire for availability
Make an EnquiryAvalue - 8th Gen Intel® Whiskey Lake Fanless Tiny System
XProduct SKU: EPC-WHL
8th Gen Intel® Whiskey Lake Fanless Tiny System
The 8th Gen Intel® Whiskey Lake-U 4 Core Ultra Low 15W ProcessorIntel® UHD Graphics 620/610Dual Gigabit Ethernet, HD AudioDual Channel Max up to 64GB DDR4 2400MhzDual Expansion, M.2 Key-B/EDual HDMI w/CEC Controller (Factory Option)TPM 2.0, RAID 0/1Support VESA (Factory Option)Features
System Information Processor Intel® Core™ i7-8665UE Processor (8M Cache, up to 4.40 GHz) Intel® Core™ i5-8365UE Processor (6M Cache, up to 4.10 GHz) Intel® Core™ i3-8145UE Processor (4M Cache, up to 3.9GHz) Intel® Celeron® Processor 4305UE (2M Cache, 2.00 GHz) System Memory 2x 260-Pin SO-DIMM Socket, Max. Up to 64GB DDR4 2400MHz BIOS Information AMI uEFI BIOS, 128Mbit SPI Flash ROM Watchdog Timer H/W Reset, 1sec. ~ 65535sec. H/W Status Monitor Monitoring System Temperature and Voltage with Auto Throttling Control SBC ECM-WHL ExpansionCONTACT US FOR VOLUME PRICING
Enquire for availability
Make an EnquiryAvalue - 8th/9th Generation Intel® Processors (6-Core/8-Core)
XProduct SKU: VMS-CFS
8th/9th Generation Intel® Processors (6-Core/8-Core)Intel® Q370 Express ChipsetIntel® UHD Graphics 630/610Memory Max. Up to 64GB DDR4 2666mPCIe,M.2 Key-E, M.2 Key-B Expansion Slots-25~70/-40C~70C Operating Temperature9~36Vdc DC Input, with Vehicle Power ManagementSupport RAID 0/1/5/10, Firmware TPM 2.0, iATM 12.0CE, FCC, IP50, E Mark, ISO7637-2 Certified
Features
System Information Processor Intel® Core™ i7-8700T Processor (12M Cache, up to 4.00 GHz) Intel® Core™ i5-8500T Processor (9M Cache, up to 3.50 GHz) Intel® Core™ i3-8100T Processor (6M Cache, 3.10 GHz) Intel® Pentium® Gold G5400T Processor (4M Cache, 3.10 GHz) Intel® Celeron® G4900T Processor (2M Cache, 2.90 GHz) Intel® Core™ i7-9700TE Processor (12M Cache, up to 3.80 GHz) Intel® Core™ i5-9500TE Processor (9M Cache, up to 3.60 GHz) Intel® Core™ i3-9100TE Processor (6M Cache, up to 3.20 GHz) Platform Controller Hub Intel® Q370 Express Chipset System Memory 2 x 260-pin DDR4 SODIMM 2400/2666MHz up to 64 GB Watchdog Timer H/W Reset, 1sec. ~ 65535min. H/W Status Monitor Monitoring CPU & System Temperature and Voltage TPM TPM 2.0 (Firmware) SBC EBM-CFSV Expansion Expansion 1 x Avalue 80-Pin IET Interface 1 x Full Size Mini PCIe (w/ push-push SIM Slot) 1 x M.2 Key-E 2230 for Wi-Fi & BT Module 2 x M.2 Key-B 2242/3042/2280 w/ push-push SIM slot for SSD/ LTE/ I/O Modules 1 x CANBus (supports OBDII, SAE J1939/ J1708 ) Storage Storage 2 x 2.5” Drive Bay (SATA III, Max. up to 12,5mm Height Storage) 2 x M.2 Key-B SSD (SATA III, Max. up to 2280) I/O USB Port 6 x USB 3.1 COM Port 2 x RS-232/422/485 (BIOS) 1 x RS-232 GPIO 1 x 8bit GPIO, w/1.5KV isolation CAN Bus CANbus modules supports OBDII, SAE J1939/J1708 (Factory Option) SIM Slot 3 x SIM Card Slot (External Accessible) Antenna 5x Antenna Mounting Hole GPS Chipset Onboard u-blox NEO-M8N module supports GPS/ Gloness/ QZSS/ Galileo/ Beidou Sensitivity Industry leading –167 dBm navigation sensitivity Product variants to meet performance and cost requirements Combines low power consumption and high sensitivity Display Graphic Chipset Intel® UHD Graphics 630 (i7-8700T, i5-8500T, i3-8100T) Intel® UHD Graphics 610 (Pentium G5400T, Celeron G4900T) Spec. & Resolution DP: Max. resolution 4096x2160 @ 60Hz HDMI: Max. resolution 4096x2160 @ 30Hz LVDS: Max. resolution 1920x1200 @ 60Hz Multiple Display Triple Displays Audio Audio Codec Realtek ALC888S supports 2-CH Audio Interface 2 x Mic-In 2 x Line-Out Certifications Certification Information CE, FCC Class A, E13 Mark, ISO 7637-2, IP50 Ethernet LAN Chipset 1 x Intel® I211AT 1 x Intel® I219LM Ethernet Interface 10/100/1000 Base-Tx GbE compatible LAN Port 2 x RJ-45 Power Requirement DC Input Typical 12/24Vdc ( +9~ 36Vdc ) DC Input Connector 3-Pin Terminal Block DC Output 12Vdc/4A DC Output Connector 2-Pin Terminal Block ACPI Single Power ATX Support S0, S3, S4, S5 ACPI 5.0 Compliant Power Mode Vehicle Power Mode (Default Setting) Industrial PC Power Mode supports AT/ATX Mechanical & Environmental Operating Temperature -40°C ~ 70C (-40°F ~ 158°F) with 0.5m/s air flow, extended temperature peripherals Storage Temperature -40°C ~ 85°C (-40°F ~ 185°F) Operating Humidity 40°C @ 95% Relative Humidity, Non-condensing Dimension (W x L x H) 239.4mm x 210mm x 110 mm(w/o wall mount) Weight 5.4KG (w/packing) 4.5KG (System) Vibration Test Operating with SSD : MIL-STD-810G, Method 514.6, Category 4, common carrier US highway truck vibration exposure Non-Operating with SSD : MIL-STD-810G, Method 514.6, Category 24, minimum integrity test Shock Test Operating with SSD : MIL-STD-810H, Method 516.8, Procedure I, functional shock=20G Non-Operating with SSD: MIL-STD-810H, Method 516.8, Procedure V, crash hazard shock test=75G Mounting Kit Wall Mount kit (Standard) Construction Aluminum + Metal Software Support OS Information Win10, Linux Ordering Information Ordering Information With Intel® Q370 Chipset VMS-CFS-87-B1-1R (i7-8700T) VMS-CFS-85-B1-1R (i5-8500T) VMS-CFS-81-B1-1R (i3-8100T) VMS-CFS-54-B1-1R (Pentium Gold G5400T) VMS-CFS-49-B1-1R (Celeron G4900T) VMS-CFS-97-A1-1R (i7-9700TE) VMS-CFS-95-A1-1R (i5-9500TE) VMS-CFS-91-A1-1R (i3-9100TE)CONTACT US FOR VOLUME PRICING
Enquire for availability
Make an EnquiryAvalue - Apollo Lake SLim Format System
XProduct SKU: NUC-APL-SLIM
NUC-APL-Slim
Intel® Apollo Lake Fanless NUC Slim SystemFeatures
- Onboard Intel® Celeron® Processor J3455/N3350 - Single DRAM Socket, Max. Up to 8GB DDR3 1866MHz - Rich I/O, 1 x COM, 2 x HDMI, 2 x LAN, 4 x USB3.0, 1 x Audio, 2 x Antennal Mounting - Expansion Slot, M.2 Key-B, M.2 Key-E - Fanless Operating from 0°C ~ 50°C - DC Power Input +12V - Compact Size, 115mm x 111mm x 45mm - Supports VESA/Din-Rail Kit - TPM 2.0 (Factory Option)Specifications
System Information Processor- Intel® Celeron® Processor J3455 (2M Cache, up to 2.3 GHz) Intel® Celeron® Processor N3350 (2M Cache, up to 2.4 GHz) System Memory- 1 x 204-pin SO-DIMM Socket, Max, Up to 8GB DDR3L 1866MHz BIOS Information- AMI BIOS, 128Mbit SPI Flash ROM Watchdog Timer- H/W Reset, 1sec. ~ 65535sec and 1sec. or 1min./step H/W Status Monitor- Monitoring CPU Temperature, Voltage with Auto Throttling Control SBC- NCM-APL Expansion Expansion- 1 x M.2 (Key-B, 2242/3042, PCIe, SATA, USB 3.0, USB 2.0) 1 x M.2 (Key-E, 2230, PCIe, USB2.0) Storage Storage- 1 x M.2 (Key-B,2242, SATA) I/O USB Port- 4 x USB 3.0 (5Gbps) COM Port- 1 x RS-232/422/485 (BIOS&Cable) Antenna- 2 x Antenna Mounting with Dust Cover System Control LED Indicator 1 x Power on/off LED & Storage Access LED on front side Display Graphic Chipset- Intel® HD Graphics 500 Spec. & Resolution- 2 x HDMI 1.4b: Max. Resolution 3840x2160@30Hz *1 x DP/DVI-I/VGA (Factory Option): Max. Resolution 1920 x 1080@60Hz *DP/DVI-I/VGA is an option which will replace the location of COM. Multiple Display- Dual Display Audio Audio Codec- Realtek ALC888S Audio Interface- 1 x Audio Jack (Mic-in + Line-Out Combo) Certifications Certification Information- CE, FCC Class A Ethernet LAN Chipset- Realtek RTL8111E Gigabit Ethernet Ethernet Interface- 10/100/1000 Base-Tx Gigabit Ethernet Compatible LAN Port- 2 x RJ45 Power Requirement DC Input- +12V DC Input Connector- Lockable DC Jack ACPI- Single Power ATX Support S0, S3, S4, S5 ACPI 5.0 Compliant Power Mode- AT/ATX (ATX is default setting) Adapter- Input: 100 ~ 240Vdc/ 50 ~ 60Hz Output: 12V/5A AC-DC 60W Adapter Mechanical & Environmental Operating Temperature- -10°C ~ 40°C (14°F ~ 104°F) with 0.2m/s air flow -10°C ~ 50°C (14°F ~ 122°F) with 0.5m/s air flow Storage Temperature- -30~70C° (-22°F ~ 158°F) Operating Humidity- 40°C @ 95% Relative Humidity, Non-condensing Dimension (W x L x H)- 115mm x 111mm x 45mm (4.53" x 4,37" x 1.77") Weight- 0.72KG (1.59lbs) Vibration Test- With SSD: 5Grms, IEC 60068-2-64, Random, 10 ~ 500Hz, 30min/Axis, 3 Axis Shock Test- With SDD : 55G, IEC 60068-2-27, Half Sine, 11ms, Z Axis Mounting Kit- VESA/Din Rail Kit Drop- ISTA 2A, IEC-60068-2-32 Test : Ed, 1 Corner, 3 Edges, 6 Faces Construction- Aluminum + Metal Software Support OS Information- Win 10, Linux Ordering Information Ordering Information- NUC-APL-34-B1-2R Intel® Celeron® Processor J3455 Fanless NUC Slim System NUC-APL-33-B1-2R Intel® Celeron® Processor N3350 Fanless NUC Slim SystemCONTACT US FOR VOLUME PRICING
Enquire for availability
Make an Enquiry
