Input Specifications:
Input Plug Type: 2-pin Molex 39-01-3028 5557 series
Input Voltage: -48VDC
Input Current: 0.5A max at -48VDC
Fuse: None
Output Specifications:
Output Plug: Output Plug: 9.5 x 5.5 x 2.1mm locking barrel plug
Output Voltage: +12VDC
Max Load Current: 1A; 2A peak for 200mS
Output Power: 12 watts continuous
Turn-On Delay: 2 second max. at -48VDC
Over voltage protection: 15V reference with output Zener Diode
Environmental:
Operating temperature: 0? to 40?
Storage temperature: -20? to 80?
Physical:
Dimensions: 74 x 49 x 40.5mm
Cord Length: 6’
Approvals:
Certifications: UL, cUL
